Mini PCIe for DELL Mini 9

Name: Mini PCIe for DELL Mini 9
Brand: KingDian
SKU: 125941887
Availability: InStock

Shenzhen Kingdisk Century Technology Co., Ltd.

Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Products Status:

Stock

Application:

Other

Type:

Internal

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Application Other

Type Internal

Style SSD

SSD Capacity Other, 4GB-128GB

Interface Type SATAII

Speed Other, N/A

Brand Name KingDian

Model Number SSD-KD-SMP-MJ5

Place of Origin Guangdong, China

Specifications

mini PCIe for DELL Mini 9
R/W Speed:165MB/s/134MB/s
SLC Nand Flash Memory
With 3 years warranty

SSD-KD-SMP-SJ5
Item	Model	SSD-KD-SMP-SJ5
	Interface	Mini PCIe SATA
Performance	Capacity(GB)	8GB	16GB	32GB	64GB
	Sustained Read	75MB/S	95MB/S	97MB/S	165MB/S
	Sustained Write	25MB/S	30MB/S	53MB/S	134MB/S
Storage Media	NAND Flash	SLC
Power Consumption	input Voltage	5V+/_5%
	Idle	0.5W
	Active	1.5W
Reliability& Endurance	Write endurance	8years @100GBytes write and erase per day at 32GB
	Read endurance	unlimited
	Wear-Leveling Algorithm	Dynamic and static wear-leveling
	Data Retention	10years at 25ºC
	MTBF	1,000,000hours
	ECC	support NCQ,TRIM 16bits or 24bits in 1024 bytes
	Bad Block Management	Auto Bad Block Management in system
Environment	Operating Temperature	0~70°C
	Non-operating Temperature	-40~85°C
	Ambient Humidity	5-95%
Warranty	2years
Available unit	Available	NO EOL
Testing Platform	Intel Celeron 336 2.80GHz,DDR2 PC2-5300 512MB×2pcs single channel RAM, VIA VT8237A VIA P4M900 Chipset,Microsoft Windows XP Professional SP2
Testing Software	HDBench3.4.0.3, IOMeter 2006.07.27
Physical Dimensions & Weight	Height(mm)	3.5±0.25
	Width(mm)	30+/_0.05
	Length(mm)	50+/_0.05
The read and write speed is limited to this test platform.
