1GB~32GB SATA DOM (Disk on Module) 4 Channles

Name: 1GB~32GB SATA DOM (Disk on Module) 4 Channles
Brand: KingDian
SKU: 125941521

Negotiable MOQ: 5 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Products Status:

Stock

Application:

Other, All PC board with SATA Interface

Type:

Internal

Shenzhen Kingdisk Century Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Application Other, All PC board with SATA Interface

Type Internal

Style SSD

SSD Capacity Other, 1-32GB

Size Other, 9.5 x23.5 X51mm

Interface Type SATA

Speed Other, N/A

Cache Other, N/A

Brand Name KingDian

Model Number DOM-KD-SA.4-MJ5

Place of Origin Guangdong, China

Specifications

1.1GB~32GB SATA DOM 4Channels
2.Max Read:51MB/s,Max Write:30MB/s
3.Capacity:1GB-32GB
4.CE,FCC,RoHS
5.With 2 years warranty

Product Name : 1GB~32GB SATA DOM (Disk on Module) 4 Channles MLC Nand Flash for Thin Client,Industrial Computer,ect,computer terminal

Item	Model	DOM-KD-SA.4-MJ5
General	interface	SATA
Performance	Capacity(GB)	1GB(1CH)	2GB(1CH)	2GB(2CH)	4GB(2CH)	8GB(2CH)	8GB(4CH)	16GB(4CH)	32GB(4CH)
	Sustained Read	30MB/S	33MB/S	73MB/s	72MB/S	73MB/S	154MB/S	155MB/S	158MB/S
	Sustained Write	8MB/S	7MB/S	14MB/s	16MB/S	15MB/S	32MB/S	35MB/S	107MB/S
	4KB Sequential Read IOPS	7179
	4KB Sequential Write IOPS	5800
	Average Access time	0.2ms
Storage Media	NAND Flash	MLC
Power Consumption	input Voltage	5.0V+/_5%
	Idle	0.5W
	Active	2.0W
Reliability& Endurance	Write endurance	8years @100GBytes write and erase per day at 32GB
	Read endurance	unlimited
	Wear-Leveling Algorithm	Dynamic and static wear-leveling
	Data Retention	10years at 25ºC
	MTBF	1,000,000hours
	ECC	Supports BCH ECC 8bits or 15bits in 512 bytes
	Bad Block Management	Auto Bad Block Management in system
Environment	Operating Temperature	0~75°C
	Non-operating Temperature	-40~85°C
	Shock	2,000G(@0.3ms half sine wave)
	Vibration	20G(40-2000HZ)
	Humidity	5-95%
Available unit	Available	NO EOL
Testing Platform	CPU:Intel® Core™ i3 Duo CPU 540 @ 3.07GHz Chipset:Intel® H55 Express Chipset Memory:Kingston KVR800D2N5/2G OS:Microsoft Windows 7 Professional 64-bit AHCI Driver:Intel® Rapid Storage Technology – Intel® ICH10R SATA AHCI Controlle v9.6 BIOS Settings: AHCI Mode
Testing Software	ATTO Disk Benchmark,CrystalDiskMark v3.0 ,HD Tach RW 3.0.1.0,HD Tune PRO 3.50
Physical Dimensions & Weight	Height(mm)	10.72+/_0.1
	Width(mm)	29.87.+/_0.1
	Length(mm)	44.07+/_0.1
	Weight(g)	TBD
Note: The read and write speed is limited to this test platform.
