KingDian IDE PATA DOM MLC 40PIN 32GB Industrial Disk On Module Solid State Drives Vertical+Socket SSD

 KingDian 4GB ,8GB,16GB,32GB 64GB Industrial 40pin IDE PATA Vertical DOM flash disk momery

                                                                         Support OEM/ODM order and good after service .

Performance:
External Transfer Rate(Host Transfer Rate):133MB/s
Interface standard: 40PIN standard IED interface
Density:MLC:1GB,2GB,4GB,8GB,16GB,32GB;
           SLC:128MB,512MB,1GB,2GB,4GB,8GB,16GB
Input voltage: 5V (±5%) or 3.3V(±5%)
Commercial operating temperature range form 0 to +70°C
Small size and don't need data line
Good shock resistant & anti-vibration performance
Upgradable: supports firmware in system programming(ISP) for firmware upgrade
FLASH Memory Support
      - Supports SLC and MLC NAND flash
      - 2K,4K,and 8K byte per page architecture
      - 2-plane structure
ECC (Error Correction Code):Hardware BCH ECC capable of correcting up to 24 bits in a 1024 byte data
Write endurance:>8 years @100GB write/ day(32GB)
Read endurance: unlimited
Data retention: 10 years
MTBF:1,000,000 Hours

What do it do?

• Speed up your system with an additional memory support that can connect to your mini ITX's IDE slot.
• The high capacity EDC (Embedded Disk card) memory storage is well suited for solidstate mass storage applications offering new and expanded functionality while enabling cost-effective designs.
• It is designed to replace a conventional IDE hard disk drive, and can be plugged into a standard IDE connector commonly found in desktop or portable PC systems.

Advantages:

• High speed for storages
• High Durability
• High endurance,Shock-proof
• Free Noise
• Light weight,Portable
• High Reliability
• Long lifetime
• Wide operating temperature:0-75'C
• Small volume,Nio MOQ
• Write protection,anti-virus
• Lower Power Consumption

Features:

• High performance and high stability data storage devices
• Extremely light weight
• Reliable & performant
• shock proof, moisture proof
• shock resistance and anti jamming
• data security solution
• Nand flash memory storage medium
• CE,FCC ,ROHS,SGS.
• write protection,notch battom

Applications:

• Automobile facilities
• Medical equipments
• Military/aerospace facilities
• Notebook and UMPC,desktop.
• Gaming and Multimedia pc
• Embedded/industrial equipments and instruments
• Mobile internet devices (mid) such as pmps,pdas and smartphones
• Enterprise computing, communications equipment/networking facilities

If you're interested in our products or for any enquiries of our items,pls freely contact me.
