Semi-auto BGA welding machine PS400
Specifications: (PS400) | |
PCB dimension |
W20*D20~W350*D350mm |
PCB thickness |
0.5~4mm |
Working table adjustment |
±10mmforward/backward, ±10mm left/right |
Temperature control |
K-type thermocouple, close cycle controlled |
PCB locating way |
Outer or Jip |
Area heater |
Infrared 3000w |
Top heater |
Hot gas 1000w |
Bottom preheat |
Hot gas 1000w |
Power supply |
Single-phase 220,50/60Hz. 5kw |
BGA dimension |
1*1~70*70mm |
Min pitch of BGA ball |
0.15mm |
Placement precision |
±0.01mm |
Max BGA weight |
80g |
Machine dimension |
L600*W600*H750mm |
Machine weight |
Approx 60kgs |
-------------------------------------------------------------------------------------------------------------------------
* The streamline design is gorgeous and room-saving, BGA Repair Solution; hot air head and mounting head are designed 2 in 1, and have both the auto soldering and mounting function.
* Upper/lower hot-air heating,bottom infrared,three independent heating areas, temperature
and time can be displayed digitally on the touch screen.
* Powerful cross flow fans cool the bottom heating zone rapidly and constantly.
* Color optical system with functions of spilt vision, zoom-in and micro-adjust, equipped with
aberration detection device; with auto focus and software operation function, 22X optical
zoom.
* Embeded industrial computer can ananlyze the two proctically-tested profiles, and compare them with the history saved profiles;profile saving no limit for the industrial computer
* Color LCD monitor, touch screen interface;
* Built-in vacuum pump;60 rotating in φ angle mounting nozzle is micro-adjustable.
* 8 segments of temperature up(down) and 8 segments constant temperature control, profile saving is unlimited in the industrial computer;
* Suction nozzle can identify material and mounting height automatically, and can control the
air pressure within a small range.
* Equipped with different hot air nozzles, easy to replace and able to locate in any angle.
* Big size splint, equipped with deformation-proof supporting device,suitable for the accurate
rework of all kinds of PCB.
* Can handle 775 socket, 478 socket.
--------------------------------------------------------------------------------------------------------------------------
Shenzhen Shuttle Star Technology Co., Ltd .is a professional manufacturer engaging in electronic equipment design, production, sale and service. It has dedicated into the R&D and production of desktop electronic equipments and frocks, and the staff are provided with rich industrial experience and pioneering spirit. The product structure and performance are improved constantly according to the market demand by introducing and absorbing the advanced technology abroad on the base of the independent innovation, at the same time we always insist on the tenet of “quality based on technology and product improved by service”and providing perfect product and service for the customer.
Ever since founded in 2000, Shuttle Star Technology has achieved the core technology with independent intellectual property with the support of new/old customers and the common effort of all staffs, especially in the aspect of special equipments for BGA rework. As the earliest domestic BGA rework station manufacturer, it breaks the historical pattern that the BGA rework station depends on the import completely at first. Now, its product series has covered the high-grade, middle-grade and low-grade and can provide complete solutions for the BGA reparation operation according to the special demand of customer.
