The most powerful BGA rework station you can ever found; very efficient repair chips including CGA, BGA, QFN, CSP, LGA, Micro SMD, MLF. Auotmatic pick and place with super high precision. Auto solder, desolder and more. Exclusive technology superior than any other similar products.
Overview:
Patents: E6250 Specification
| Item | Parameter |
| Model: | E6250 |
| Machine Size: | L780*W850*H950mm |
| Machine Weight: | Appox. 150kg |
| Working Table Micro Adjust: | 13mm FWD/BWD, 13mm L/R, 360 rotatable nozzle |
| Temperature Control: | K-type thermocouple, close loop controlled |
| Power Supply: | Single phase 220V, 50/60Hz |
| Top Heater: | Hot air,1000W |
| Lower Heater: | hot air, 1000W |
| Bottom Heater: | Far infrared, 3000W |
| Workable PCB Size: | W20*D20-W400*D450mm |
| Workable PCB Thickness: | 0.5-4mm |
| BGA Min. Pitch: | 0.15mm |
| Max. BGA Weight: | 300g |
| Applicable BGA Size: | 1*1-70*70mm |
| Placement Precision: | 0.01mm |
| Gas Supply: | 90L/min |
- Standard wooden case with machine fixed inside.
-
5 working days after get payment.
| Item | Qty. |
| BGA Reball Kit(BK98D) | x 1pc |
| Stencil/Mask | x 33pcs |
| Solder Paste/Flux | x 1tin |
| Leaded Solder Ball(0.45, 0.5, 0.6mm) | x 3tins |
| Upper Nozzle(five for upper, two for bottom) | x 7pcs |
| PCB Clamp for Laptop Motherboard | x 1set |
| Temperature Measurement Wire | x 1pc |
| High Temperature Cloth | x 1pc |
| Hex Key Wrench-set | x 1pc |
| Aluminum Plate | x 1pc |
| Suction Pen | x 1pc |
| Brush | X 1pc |
Shenzhen Shuttle Star Technology Co., Ltd. is a professional manufacturer engaging in electronic equipment design, production, sale and service. It has achieved the core technology with independent intellectual property with the support of new & old customers and the common effort of all staff, especially in the field of special equipments for BGA rework and inspection.
Our company has dedicated into the R&D of the new products and the improvement of technology for more than 15 years. Now, our product series has covered from high-end to low end and can provide complete solutions for the BGA repair operation and inspection according to the special demand of customers. We welcome all custmers from home and abroad to cooperate with us.
