Help CenterTubular Motor for Roller Shutter
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
SCVE
Model Number:
SF92-N-M
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
AC Tubular Motor With Dia. 64mmNegotiableMOQ: 300 Sets -
Tubular Motor 500Nm With Manual SF115M1NegotiableMOQ: 50 Poles
-
Tubular Motor 500Nm With Manual SF115 M2NegotiableMOQ: 50 Poles
-
Tubular Motor 64mm With Manual for Rolling Shutters SF64MNegotiableMOQ: 300 Poles
-
Tubular Motor 500Nm With Manual for Rolling Shutter SF115 M2NegotiableMOQ: 50 Poles
Place of Origin
Zhejiang, China
Brand Name
SCVE
Model Number
SF92-N-M
Specifications
Tubular MotorType:SF92-N-M
140-300Nm
They are widely used for large garage doors for airplane,
roller shutters etc.
About SF92-N -M Series:
SF92-N -M series tubular motors are designed by international advanced technology, with merits of Safe, Compact, Vogue and Effective, adopt side-magnetic brake system. The output torque is from 140N.m to 300N.m.They are widely used for large garage doors for airplane, roller shutters etc.All our products are CE.TUV.UL.OHS certificated.
Model |
Torque |
Speed |
Rated Voltage |
Rated Frequency |
Rated Power |
Rated Current |
LimitTurns |
|
N.m |
r.p.m |
V |
HZ |
w |
A |
Turn |
SF92-N-140M |
140 |
12 |
230 |
50 |
580 |
2.6 |
12 |
SF92-N-180M |
180 |
12 |
230 |
50 |
626 |
2.8 |
12 |
SF92-N-230M |
230 |
12 |
230 |
50 |
830 |
3.6 |
12 |
SF92-N-250M |
250 |
8 |
230 |
50 |
850 |
3.7 |
12 |
SF92-N-280M |
280 |
8 |
230 |
50 |
860 |
3.75 |
12 |
SF92-N-300M |
300 |
8 |
230 |
50 |
880 |
3.8 |
12 |
SF92-N-330M |
330 |
8 |
230 |
50 |
910 |
4.0 |
12 |
