SCVE Roller Shutter Motor/92mmTubular Motor
Specifications
1. Best quality tubular motor2.Tube adaptors to suit 97mm to 135mm
3. single phase motor
Company File: Zhejiang Huzhou SCVE Machine&Motor Co.,ltd is a professional manufacturer in tubular motors and relative accessories in China.
With many years' experience, we have established a skilled team with high technology, who are dedicated to investigating and developing new tubular motor constantly .
At present, SF series tubular motor already have the most completed models from 3N.M to 500N.M in diameter of 35mm(SF35series), 45mm(SF45 series), 59mm(SF59 series), 64mm(SF64 series). 92mm(SF92 series), 115mm(SF115 series). With or without manual override for your various choices, please link our website: www.scvemotor.en.china.cn to get more details about our products. All of products are CE, TUV, ROHS, UL certificated.
Specifications:
SF92 M2
Model |
Torque (N.M) |
Rotating (rpm) |
Rated Voltage (V) |
Rated Frequency (Hz) |
Rated Power (W) |
Rated Current (A) |
Limit Turns (turn) |
Protection Index (IP) |
Running Time (min) |
Net Weight (KG) |
| SF92 140M2 | 140 | 12 | 230 | 50 | 580 | 2.6 | 12 | IP44 | ≥4 | 13.5 |
| SF92-180M2 | 180 | 12 | 230 | 50 | 626 | 2.6 | 12 | IP44 | ≥4 | 13.5 |
| SF92-230M2 | 230 | 12 | 230 | 50 | 830 | 3.6 | 12 | IP44 | ≥4 | 13.5 |
| SF92-250M | 250 | 8 | 230 | 50 | 850 | 3.7 | 12 | IP44 | ≥4 | 14.6 |
| SF92-280M2 | 280 | 8 | 230 | 50 | 860 | 3.75 | 12 | IP44 | ≥4 | 14.6 |
| SF92-300M2 | 300 | 8 | 230 | 50 | 880 | 3.8 | 12 | IP44 | ≥4 | 14.6 |
| SF92-330M2 | 330 | 8 | 230 | 50 | 910 | 4.0 | 12 | IP44 | ≥4 | 14.6 |
Range of application: garage door, shop shutter, industrial door
