2015 Newest used cnc wire cut machines
Technology parameters:
| Model | JP1224 | |
| Item | Description | Parameter |
| 1 | X, Y, Z working area | 1220*2440*120mm |
| 2 | Table size | 1294*2760mm |
| 3 | Resolution | ± 0.03/300mm |
| 4 | Repeatability | ± 0.02mm |
| 5 | Lathe structure | Cast steel |
| 6 | X structure | Ball screw, shaft rails |
| 7 | Y structure | Ball screw, linear rails |
| 8 | Z structure | Ball screw, shaft rails |
| 9 | Max. consume power | 4kw |
| 10 | Max. rapid | 0-6000mm/min |
| 11 | Max. working speed | 0-3000mm/min |
| 12 | Spindle power motor | 1.5kw chinese self-coolant spindle, ER16 |
| 13 | Spindle speed | 0-24000RPM |
| 14 | Working mode | Stepper motor |
| 15 | Working voltage | Single phase AC220V/50HZ/60Hz |
| 16 | Command code | G Code(*uoo,*nc,*mmg, *plt) |
| 17 | Operating System | DSP system or Mach3 system |
| 18 | Interface | Printer port 50pins or USB |
| 19 | System memory | 128M (or pen driver) |
| 20 | Collet | ER16 |
| 21 | X, Y working delicacy | <0.01mm |
| 22 | Software | Type3 software, ucancam software, copy artcam software |
| 23 | Running circumstance | Temperature: 0°C~45°C |
| relative humidity: 30%~75% | ||
| 24 | Packing size | 3100*1850*1650mm |
| 25 | Net weight | 650KG |
| 26 | Gross weight | 750KG |
Feature :
1. The traveling speed can reach 35m/min. high-speed cutting speed can reach 25m/min.
2. The whole machine adopts robust structure, powerful spindle motor, precise and efficient control system, coming with professional software. It is easy to install and operate.
3. 32M memory capacity can store many files simultaneously and read at random.
4.Gantry movement, casting table is more durable. It will not bend after long time use. The position precision is much better.
5. Compatible with CAD/CAM software,such as TYPE3/ARTCAM/ARTGRAVE/UCANCAM/CORELDRAW etc.
Sample show:
Machine parts :
Jinan Precision Machinery is high-tech company which is specialized in Research
and develop various cutting and engraving machinery. We learn from foreign advanced
technology, adopt imported high quality spare parts to guarantee machine quality.
Our products have approved CE FDA certificates .
Main product: CO2 laser machine, Fiber laser machine, CNC router, Plasma cutting machine.
our factory
Our Cooperation brand
our Partner
1.Before-Sale:we will try to know your requests about what work you will do and help you choose the most suitable
machine specification & give you the best solution.
2.During Production: we will send photos of machines during production. so customers can know more details about
the procession of making their machines and give them suggestions.
4.After Shipping: we will give you the tracking information of the sea vessel so customers can know when it will arrive
at your port and make enough preparation.
6.About Training: there are some manual and video about how to install & use machine , if you have any questions
you can contact me any time, then i arrange our professional technicians to help you by video, pictures,call or email.
7. About Warranty: 12 months for the whole machine.Within 12 months under normal use and maintenance, if something
is wrong with the machine, you will get spare part for free.
8. Service In Life-Time: No matter how many years passed, you always can contact me, we can give you any technical
support in the future life-time.
Q. Can the machine engraving and cutting?
A. Yes, even on the same Job, you can do setting with different colour in the software and also
can making holes.
Q. is the machine must work with computer?
A. Must connect with computer with USB cable when you change the settings of machine.
for the design files,
you can transfer the file with USB memory stick to the machine, Or can download it to the
machine directly with USB cable from computer.
Q. Can the machine be split so it can fit into my doors?
A. no, it can't.But when your order,you can tell us your door width,We will custom make
the machine according to your condition.
Q. How long the laser tube is working well?
A. It is about 10000 hours,but it is also depend on your work and maintain.
Q. Is spare parts available ?
A. we can provide all of spare parts of any model we listing.
Q. I have heard the mirrors need cleaning?
A. Yes they do but not after every job, once a week is normally enough
Q. How about the after sell service?
A. 2 years for the whole machine Free tech support for the whole life of the machine,
and 24 hours telephone support. Camera of MSN support by MSN or skype online
when you need.
