2013 High Efficiency Stone Fine Crusher With Low Price

2013 High Efficiency Stone Fine Crusher With Low Price photo-1
US$ 1,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Impact Crusher
Capacity(t/h):
20-25
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Impact Crusher
Capacity(t/h) 20-25
Place of Origin Henan, China
Brand Name zhongcheng
Model Number PFX800*300
Application Rock & Mineral Operations

Specifications

1. High crushing efficiency
2. Large crushing ratio
3. Less power consumption
4. Low production costs

   High efficiency energy saving stone fine crusher with low price



                          2013 High efficiency stone fine crusher with low price





This series of crushers has been developed and improved by incorporating the advantages of the technology both home and abroad so that the structural design is further optimized. Uses in all kinds of medium degree hardness solid material, cement industry for crushing limestone, paste, chamotte, mix material and so on. Also may be used for fine crushing the calcium phosphide, the dolomite, and pearl ore and so on. It can be widely used in the building materials, the chemical fertilizer, mining industry sector and fire-proof material and so on.



1.Working principles of high-efficient fine impact crusher:



This equipment adopts two motors, which take two rollers to rotate reversely by the decelerator. When the materials drop on the rollers through the charge hole under the friction of the rollers, they are dragged between the two rollers, grinded by the roller's crushing; the grinded materials are pushed prefatorily by the rollers.





   2013 High efficiency stone fine crusher with low price



2.Features of high-efficient fine impact crusher:



1. Small and uniform particle size

2. Large capacity, hammer, long life

3. Supporting smaller power

4. Simple process and structure, easy maintenance, smooth operation



       2013 High efficiency stone fine crusher with low price





3.High-efficient fine crusher's main technical parameters:



Type

Material-in size(mm)

Material-out size(mm)

Yield(t/h)

Power(kw)

Weight(t)

PFX800×300

<=60

<=5(96%)

20-25

37

2.5

PFX800×600

<=60

<=5(94%)

35-50

45

4.7

PFX800×800

<=70

<=5(92%)

40-60

75

6.5

PFX1000×1000

<=80

<=5(91%)

60-90

90

8.8

PFX1000×1200

<=90

<=5(88%)

75-110

110

13.6

PFX1300×1200

<=100

<=5(86%)

120-145

160

19.5

PFX1300×1400

<=120

<=5(85%)

145-180

180

26



   2013 High efficiency stone fine crusher with low price
