Home > Electrical & Electronics > Passive Components > Capacitor > Coin Acceptor for Game Machine

Coin Acceptor for Game Machine

Name: Coin Acceptor for Game Machine
Brand: TOTEM
SKU: 125839079
Availability: InStock

Coin Acceptor for Game Machine thumbnail-1

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

TOTEM

Model Number:

TM315

Contact Supplier Request Quote Chat Now

Guangzhou Dayu Hardware & Electronic Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name TOTEM

Model Number TM315

TOTEM coin acceptor suit for game machine,pc station,time comtrol,we can offer usb and protocol for the develop,program if need on various machine.

Specification:

1.Operate with the game machine’s standard. Switch to the correct mode with Normal Open(N.O) and Normal Close (N.C.) Usually use Normal Open .

2.Switch to the correct speed (pulse) of coin machine.

FAST :25ms(short pulse signal)

MEDIUM:45ms(medium pulse signal)

SLOW:65ms(long pulse signal by TIMER SWITCH for synchronizing with your machine)

3.When the coin acceptor is used , the coin setting switch needs to be set correctly according to the coin that was selected .

4.The switch which for adjusting the coin’s value , can setup several coins come out one signal or cancel the programmed coin.When program the several coins come out one signal, the initial setting is two tone “BI~BI”, it means after you deposit two coins it’ll send out one signal .Press the switch again, it’ll have one more “BI” tone ,and like the same,the more it’ll happen five coins come out a signal .

5. The switch for test the coin’s sensitive degree, it detects the difference between real/fake coin ,when inserted .

6.Please turn power about 10 minutes before using or setting,you can get
the optimal effect.

7. Connecting instructions of connector:
Red line ——DC+12V (V+)
White line——COIN Signal (COIN)
Black line ——Ground (GND)
Brown line——Counter (COUNTER), (when don’t connect to counter, this line can unused)

Blue line——Control line (CONTROL), (if necessary)Apply to coin's
