200 kg/h stainless steel cocoa grinder, cocoa bean grinder

cocoa processing machine, cocoa processing line, cocoa processing production line

This cocoa process line is used to make cocoa liquor, cocoa butter and cocoa powder,

We also have chocolate processing equipment.

The equipment include cocoa roaster, cocoa winnower, cocoa liquor machine, cocoa cake/liquor crusher and grinder, hydraulic cocoa butter press machine, cocoa powder making machine and so on.

1. cocoa roaster

the process of cocoa roaster: the cocoa bean should be roasted at high temperature 100-120 degree ,

The whole process takes about 30 minutes to ensure that every cocoa beans after roasting, exudes a rich cocoa flavor.

the temperature of the roasted can be sdjustable as your requiement.

Technical parameter:

pictures of cocoa roaster

We also have cheaper price type cocoa bean roaster, you can check the picture as following:

2. cocoa liquor making machine, cocoa mass making machine

the grinder machine grind the cocoa bean into paste/ butter called cocoa liquor, also known as bitter cocoa material.

Warmed Cocoa liquor having the characteristics of the fluid,  cooled cocoa liquor into block.

The technial data of cocoa liquor or cocoa mass

the picture of full stainless steel cocoa liquor machine

 3. cocoa cake crusher machine

this crusher machine not only increase the cut angle of blade, but also adopt the blade carries, so that it can distribute pressure of blade, improve the shear and bear impact force of each blade. Blade adopt alloy steel which accord to the special heat treatment, highly abrasion resistance and thin sharp of the blade with several times.

it can be used to crush the bigger raw material into small pieces, the grinder machine can grind the crushed raw materail into powder which can be 80 mesh 120 mesh 180 mesh 200mesh and so on.

the technical data of cocoa bean/ cake crusher

please check the picture of full stainless steel crusher as following:

We also have a cheaper type cursher machine, please check the picture as following:

4. cocoa bean grinder/ cocoa cake grinder

1, Material

The machine is made of SUS304 stainless steel which adopts to the international standards of food hygiene.

2. main use

this machine can be used in many fields: such as coffee/cocoa grinding, pharmaceutical, chemical, mining, abrasive, refractory, non-metallic minerals, metalergy, building materials, medicine, food, pesticides, feed and other trades.

3, Main Advantage

3.1 Compact structure, small occupied area.

3.2 No storage, no dead angle,easy to disinfect and convenient to change variety. Our machine is consistent with the GMP standard.

3.3 Apply to wide particle size range,product particle size is in the 10 to 300 mesh, so you can choose any size between 10 and 300 mesh.

3.4 negative pressure manufacture, no dust pollution and good environmental quality

4. working principle

When the main shaft rotates at a high speed, the rotor disk runs at the same time,the materials are put into the hopper and move

automatically through the feeder into the crushing chamber. In the crushing chamber the material is crushed in the comprehensive

effect of  mutual impact, shear and friction between the teeth and the material.

The machine is equipped with mesh screens,the screen can be changed in accordance with customer requirements.

The grinded materials are drove by the airflow and are impacted and  rubbed by the teeth and hammer slice again and again.

When the material to be pulverized to less than sieve diameter,it can rapidly get out of the crushing chamber through the sieve

pore and falling to the outlet, and the coarse material is continue to be grinded.

5. the technical data

6. the picture of full stainless steel cocoa cake grinder

 the sieve of cocoa grinder

5 cocoa butter making machine/ cocoa liquor press machine

We can use hydraulic press machine to press the cocoa liquor to get the cocoa butter and cocoa cake.

We can use the cocoa butter to make chocolate, and use the cocoa cake to make cocoa powder.

the technical data

The picture of hydraulic cocoa butter making machine

The stainless steel  of hydraulic press drum

We also have cocoa winnower machine, please check the pcitures as following:

please check the cocoa bean sorter machine as following:

If you have any question, please contact me no hesitate!!!
