PD1141A small diaphragm pumps with mechanical relief system
Pressure adjustable quad-head diaphragm pump
Optimal for dispensing and recovery of ink in industrial ink jet printers
Equipped with mechanical relief system
This quad-head pump is developed to be built into industrial ink jet printer.
You can freely combine the four heads either independently or parallel to one another.
Besides ink, it is also available for alcohols. The head is made from POM and the diaphragm is PTFE.
Based on solvent type, the O-ring can also be made with Kalrez.
Available power supply includes 24VDC, 100VAC, 220VAC, and 230VAC.
Order quantity must be multiple. Please inquire for details.
Specification Table
| Fluid Types | IPA, solvent-based dye inks | ||
| Wetted Materials | POM, PTFE, EPDM, SUS304 | ||
| Discharge Pressure | range of 0.3–0.5 Mpa can be set | ||
| Maximum Discharge Rate | 95mi/min per head (methanol) | ||
| Power Supply | 24VDC, 100VAC, 220VAC, or 230VAC | ||
| Operating Temperature | 0~40℃ | ||
| Ambient Humidity | 35~90% RH | ||
| Part of PeriodicReplacement | diaphragm (8,000H) | ||
| Weight | approximately 3kg |
Other related product - small diaphragm liquid pump
Strength of Hemmi' pump
Small to medium diaphragm pumps are optimal for medical and food industry
Quad-head diaphragm pumps is developped for use in industrial ink jet printers
Sampling pump is essential for gas analyzing.
Misato Plant
- Sales/production system ensures efficient management from initial procurement of order to final shipment.
- Components are cleaned by environment-friendly washing system to ensure high-quality of product.
- Wiring/Assembly/Testing are conducted in fully equipped clean-room with class of 1,000-10,000.
- Our team are ready to provide total solution from R&D, manufacturing till Quality Assurance to achieve customer's satisfaction.
ISO Certificate
2000 Acquired ISO 9001 certification
2005 Acquired ISO 14001 certification
Company Profile
| Company Name | HEMMI Slide Rule Co., Ltd. | ||
| Website | .jp | ||
| Established | April 15th, 1895 | ||
| Capital | 100million yen | ||
| Head Office | 4-4 Kanda-Surugadai, Chiyoda-ku, Tokyo | ||
| Plants | Higashimatsuyama Plant & Misato Plant | ||
| Operating Business | Design, manufacturing and sales of Printed Circuit Board, Industrial Equipment's and Analytical & Testing Devices | ||
| Branch | Taipei Branch F11, No.156 Min Sheng East Road, Sec.3 Taipei |
||
| Staff | 90 | ||
| Affiliates | FT.Okura, Inc. |
||
| Hemmi Kigyo Co., Ltd. http://www.hemmi.jp | |||
Business Information
| Printed Circuit Board | •circuit & pattern design | ||
| • manufacturing of printed circuit board | |||
| • components assembly | |||
| • restoration design | |||
| Industrial Equipment | • fluid controlling devices | ||
| - high precision flow rate control valves; | |||
| pressure control valves | |||
| - small diaphragm pumps | |||
| • semi-conductor manufacturing devices & related | |||
| equipment | |||
| Analytical & Testing Equipment | • catalytic testing equipment | ||
| • fuel cell testing equipment | |||
| • catalytic gas adsorption measuring equipment | |||
Displayed products selected from whole line-up are versatile for various applications.
Your enquiries and ideas are welcome.
It’s our honor to have chance to assist you and
we expect to broaden cooperation with more trusted partners.
