Specifications of long span galvanized corrugated steel roofing sheet:
long span corrugated sheet
standard;JIS,GB,ASTM,BS,AISI,DIN
grade;SGCC,DC51D,DX51D,SPCC
Type: YX28-207-828
thickness;0.12-0.8mm
width::750-1200mm
length:1.5-3.0m or as client's requirement
application:used as wall or roof in warehouse,factory,garagem exhibition center
surface;regular spangle, big spangle, small spangle
The color coated steel, galvanized sheet by cold rolled into a variety of wave plate used in construction line.
Such as: for industrial and civil buildings, warehouse, special construction, large span steel structure buildings,
walls, and other internal and external wall hangings
Products name
Color coated cold rolled steel sheet, Prepainted cold rolled steel coil, Color cold rolled steel coil ,Prepainted galvanized steel coil, coated zinalume steel coil ,corrugated roofing sheet, Prepainted galvalume steel coil, Color coated galvalume steel coil, Prepainted galvanized steel plates
Thickness
Pre-painted cold rolled coil:0.13mm-1.2mm
PPGI and PPGL: 0.17mm-0.7mm
Width
Pre-painted cold rolled coil:0.13mm-0.16mm:1000mm;
0.17mm-0.23mm:914mm,1000mm,1200mm,1250mm
PPGI and PPGL: 800mm-1250mm
Color
common: blue , ivory beige ,orange, , bush green , nut brown , gray beige ,
specific: crimson, green, ivory, orange, and RAL cold.
Coating thickness
Top: 13-20um
Back: 5-7um
Paint PE, PVDF, SMP, etc. Glossy25%-80%Tolerance
Width:+/-0.02mm
Thickness:+/-0.02mm
Zinc coating
Pre-painted cold rolled coil: 0-30gsm
PPGI: 40-100gsm
PPGL: 55% Alu+43.5%Zn+1.5%Si (30-50gsm)
Packing
Each bare coil to be securely tied with two bands through the eye of coil (or not) and one circumferential, the contact points of these bands on the coil edge to be protect with edge protectors. Coil then to be properly wrapped with water proof /resistant paper, it then to be properly and completely metal wrapped. And each packed coil to be properly wrapped with band, three-six such band through the eye of coil at about equal distance, and two four such bands securely tied around belly of coil at about equal distance
