organic fertilizer compost turning machine
Compost turner is used to turn ans mix loose material such as agricultural stalks, various grasses, sugarcane and corn leaf, agricultural waste and househould waste, and sticky materials such as animal manures, ect.
Organic Fertilizer Turning Machine Features
1.Crawler compost turner consists of the following parts such as crawler walking system, compost turning system, machine rack and turning part. Hydraulic system controls its turning and main working parts, therefore, the turning and transmits are flexible and reliable.
2.Before fermentation, heap the compost in a strip according to a certain width and height, at the same time, spread strain to help decompose microorganism by hand or automatic spreading strain device.
3.Then it is the compost turner that blend and crush compost materials.
4.During turning or blending, compost material is taken high due to rotary drum high speed and moves backward for a certain distance for scattering and crushing.
Technical date of A compost bin crawler turning machine
turning width |
2300mm |
rated power |
56kw/2200r/min |
turning height |
1.1m |
max processing capability |
700-800m³/h |
track width |
2×0.28m |
speed of advance
|
0-8m/mins |
|
Accumulation spacing
|
0.6m |
astern speed
|
0-8m/mins |
max material particles |
250mm |
radius of turning circle |
2000mm |
processing capacity |
7.58m×60×2.8m×1.2m÷2=760 |
||
engine brand |
Diesel 4102 engine |
||
About Henan Wanfeng Machinery Manufacturing
It is located in Henan Hebi city demonstration area of urban and rural integration, and it is devoted to the development of ecological agriculture, improving the ecological environment, protecting human health as the first goal, organic fertilizer equipment research and development, production, sales, application, promotion and technical services in one of the high-tech enterprises.
The Company has products that suitable for organic fertilizer and biological organic fertilizer production, such as fermentation equipment,screen system, batching system, granulation, drying equipment cooling equipment such as a full set of machinery, relying on the well known experts years of research and practice who come from the Chinese academy of agricultural sciences, China agricultural university and other colleges and universities. The company is the domestic research and development production of organic fertilizer production equipment and a complete set of production line of the rapid growth of the enterprise,and the organic fertilizer plant construction to provide the best overall design scheme of enterprise.
