Soundaware A280C HiFi 32Bit/192KHz Pure DSD Music Player with Independent DAC Headphone Amplifier

Soundaware A280C HiFi 32Bit/192KHz Pure DSD Music Player with Independent DAC Headphone Amplifier

Description

A280C is a super desktop with concise,convenient,utility features

The design of A280C is based on soundaware national patented professional high-fidelity streaming music playback architecture,which bases on the FPGA and dual native audio crystal oscillator to decode the audio file,obataining highest performance and minimum jitter

Independent DAC/Headphone AMP/Preamp Professional Digital output

A super Desktop Player intergrating the Convenience,Utility and Hi-Fi Sound

Since the beginning of 2013,soundaware started developing one player,which could support decoding DSD format files directly,instead of converting DSD data into PCM firstly,that used on all of the present high fidelity playback products at that time,Until 2014,after obtaining the program of 1 Bit DSD original playback,R&D have to conquer the barrier of developing another effective control method and circuit module.Ultimately,they succeed and apply the original playback architecture to high fidelity products.

Specification

Input interface
SD*1:theoretical maximum storage is 2TB,actual inspect is 128GB
Support the format of FAT32 and NTFS
USB*2(POWER SUPPLY 500ma*2):support USB1.0,USB1.1,USB2.0,compatible USB3.0,hard disk 4TB and 2TB partition,both at Maximum
Internet:100Mbps Full Duplex,support NAS(Samba),UPNP/DLNA V1.5
Power supply:230V or 115V(sees the specification on the package,)50-60hz
Coaxial Input:16-24bit,44.1khz-192khz PCM
Optical input: 16-24bit,44.1khz-96khz PCM

Output interface

1 Digital output
Coaxial output:16-24bit,44.1khz-192khz PCM;DSD64 DOP1.0
Optical output: 16-24bit,44.1khz-96khz

2 Analog output
RCA*2 1.8V RMS THD+N:<=0.003%(44.1KHZ,1KHZ DS3)
Phone Out: 8.5V RMS THD+N:<=0.002%(44.1KHZ,1KHZ DS3)

Other Specification
Power dissipation <15W(NO USD hard disk),standby dissipation<=5W
Dimension:240W*103H*305Dmm
Weight(with the package):6kg

Package
1 x A280C Player
1 x Cable Wire
1 x Power Line
1 x User Manual
1 x 16G SD Card
1 x Warranty Card
1 x Remote Control
