HIFIDIY.net Mini 1793 SPDIF DAC Board -PCM1793+DIR9001
USD $48 - $55
/ Piece
5 Pieces(Min.Order)
- shenzhen
- Credit Card
You May Like
-
HIFIDIY.net USB AMP,Headphone Amplifier @ PCM2707 USB
-
Fumusic MDS-623 Tube-preamp & &6N3 & Matisse design AMP
-
Matrix mini-i 24/192 Balanced USB DAC & Headphone Amp Quality guarantee 100% Grinding and tubes One year warranty
-
Little Dot MK 2 II Headphone Amp Amplifier/Pre-Amp Tube Amplifier
-
Little Dot MK I+ Portable Headphone Amp 2 channel Amplifier
-
Little Dot MK I+ MKI+ Portable Head-AMP & Standard Edition
Product Details
| Brand Name | HIFIDIY | Model Number | Mini 1793 | |
| Type | Home Amplifier | Channels | 2 (2.0) | |
| Place of Origin | Guangdong, China |
Product Description
Specifications
Mini 1793 SPDIF DAC Board -PCM1793+DIR9001100% Quality Guarantee
Mini1793 DAC---SPDIF+OPTICAL DAC Board (PCM1793+DIR9001+OPA2134)
FEATURE:
This Mini DAC made with high-quality component......Nichicon capacity, WIMA capacity
Main DAC: Burr-Brown PCM1793
--24-Bit 192kHz Sampling Advanced Segment Audio Stereo DAC
--Dynamic Range: 113 dB THD+N: 0.001%
--8× Oversampling Digital Filter
This DAC can use for multimedia system, satellite radio, CD player and DVD
player(two channel)
Digital input receiver DIR9001
--The receiver used is more expensive and of better quality than the popular CS8412/4/6
used in all other DACs. It has many more music details and accurate sound you obtain.
OPAMP: Burr-Brown OPA2134
Coaxial / Optical Input , Analog Output
Short signal path,Such as double side gold coat PCB with high quality soldering.
Power Supply: DC 12V , 1A (Positive Center) (Not Include Power supply)
PCB Dimension: 100mm * 60mm
Weight: 0.150kg
Packing: PP bag
Download its Schematic /soft/PCM1793DAC_sch.pdf
Mini TDA1543 DAC with Mini PCM1793 DAC comparison:
Mini TDA1543 DAC: more music taste, sounds more tube like warm(LP taste)(Midrange is sweet ,but weakness in the high frequency reproduction),
Mini PCM1793 DAC: sound closer to the high-fidelity, high frequency is extremely fine
Mini TDA1543 DAC with Mini PCM1793 DAC comparison:
Mini TDA1543 DAC: more music taste, sounds more tube like warm(LP taste)(Midrange is sweet ,but weakness in the high frequency reproduction),
Mini PCM1793 DAC: sound closer to the high-fidelity, high frequency is extremely fine
