Little Dot MKVIII MK8 SE 12AT7X2 6H30PIX4 Balanced Tube Headphone Amplifier
The Little Dot MK VIII SE further specializes our Little Dot MK VI+ platform for no-compromise performance with high impedance headphones. Fully balanced architecture with single-ended headphone functionality as well, the Little Dot MK VIII SE is also dual-mono with independent amplifiers with their own isolated toroidal transformer power supplies. An output capacitor-less design minimizes components in the signal path, delivering a "pure" signal free from unwanted distortion and color. The Little Dot MK VIII SE's sound signature is designed to be provide a reference-level of transparency with a touch of tube warmth and tonal richness.
Buying sample in our AliExpress Retail Store
http://goo.gl/gYs5wE
TECHNICAL SPECIFICATIONS:
Available in either Black or Silver
Fully Balanced, Dual-Mono Architecture
Inputs:
Balanced: 2x 3-pin XLR
Single-ended: 2x RCA
Outputs:
Balanced: 4-Pin XLR
Balanced Pre-Amp: 2x 3-pin XLR
Single-ended: 1/4" (6.35mm) TRS Stereo jack
Frequency Response:
Input Impedance: 50K ohms
5Hz - 80KHz (-3dB)
10Hz - 30KHz (-1dB)
Pre-Amplifier Output Impedance: 600 ohms
THD+N:Signal-to-Noise: 96 dB0.01% (2Vrms @ 1000Hz)
0.03% (10Vrms @ 1000Hz)
0.2% (20Vrms @ 1000Hz)
Power Output:
Voltage Swing: 60V p-p
2W per channel @ 600 ohms
1W per channel @ 300 ohms
Power Consumption: 110 VA
Metric: 350mm (length) by 290mm (width) by 140mm (height)
Weight: 9.6 kg or 21 lbs
Available in either 110-120VAC or 220-240VAC
One Year Official Little Dot Warranty
1.Voltage
Can you change the voltage and plug?Our voltage is 110V or 220V,and our plug is EU,US or others.
Yes,we will change the voltage and plug according to your shipping address.
2.RMA
Hi seller,I bought one device from your shop before,but it is broken now under warranty,can you help me repair it?
Yes,please send the defective device or wrong device to our Chinese address(please contact our salesman).
Once we received it,we will send you the new replacement or refund immediately.
3.Warranty
I bought your product 7 years ago,but it's broken now,can you repair it?
Oh...Dear friend,our warranty is 1 year,would you like have a try of the newest one?
4.Samples
Hi,man,I love your products too much,can you send me a sample to test?I will place big order in future.
Hi,my friend,Please buy products from our Aliexpress store directly.
/store/601461
5.Shenzhen Shop
Hi,brother,I am going to Shenzhen,China,can I visit your shop?
Yes,my friend,welcome to our shop,you can have a try of your favorite devices,and it would be better if you could inform me in advance,so I can prepare for your needed devices.
Shop address: 4F9,No.3018,Gume,Wanshang Electric City,Huaqiang north road,Futian zone.Shenzhen,China.
T:86-0755-82521355
