YAQIN MS-300C Class A Stereo Single End Integrated Tube Amplifier

YAQIN MS-300C Class A Stereo Single End Integrated Tube Amplifier thumbnail-1
YAQIN MS-300C Class A Stereo Single End Integrated Tube Amplifier thumbnail-2
YAQIN MS-300C Class A Stereo Single End Integrated Tube Amplifier thumbnail-3
YAQIN MS-300C Class A Stereo Single End Integrated Tube Amplifier thumbnail-4
YAQIN MS-300C Class A Stereo Single End Integrated Tube Amplifier photo-1
YAQIN MS-300C Class A Stereo Single End Integrated Tube Amplifier photo-2
YAQIN MS-300C Class A Stereo Single End Integrated Tube Amplifier photo-3
YAQIN MS-300C Class A Stereo Single End Integrated Tube Amplifier photo-4
US$ 707.94 - 782.46 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
YAQIN
Model Number:
MS - 300C
Type:
Professional Amplifier
Contact Supplier Request Quote Chat Now
Shenzhen Longruixiang Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name YAQIN
Model Number MS - 300C
Type Professional Amplifier
Channels 3 (2.1)
Place of Origin China

YAQIN MS-300C 9.5WPC 300B x 2 Vacuum Tube Hi-End Tube Integrated Amplifier



You can place order from Aliexpress retail store:

/store/product/YAQIN-MS-300C-9-5WPC-300B-x-2-Vacuum-Tube-Hi-End-Tube-Integrated-Amplifier/601461_32626825576.html



Technical Specifications



Tube: 300B × 2 (Output Tubes)

           6N8P × 2 (Drivers and Cathode followers)

           12AT7 × 2 (Voltage amplifiers)

            5Z3P × l (Rectifier)

Maximum Output: 9.5W × 2 (8Ω)

Output Jacks: Two channels with two groups of gold plated jacks

                        Headphone jack on the front panel

Speaker Output: Impedance: 4Ω and 8Ω

Headphone Output: Impedance: 32Ω (Recommended)

Input Jacks: Four groups of gold plated isolated RCA jacks

Input Sensitivity: 0.3V

Distortion of Harmonic Wave: ≤1% (at 4W)

Frequency Response: 5Hz ~ 35KHz (-2dB)

Signal-to-Noise Ratio: >89dB (A weight)

Remote Controller: Infrared control and powered by 2 AAA batteries

Supply Voltage: AC 115V 60Hz

Power Consumption: 200W

Net Weight: 23kg (50lb)

Net Dimension: 48cm (W) x 36cm (D) x 24cm (H)

Shipping Weight: 28kg (61lb)

Shipping Dimension: 60cm x 50cm x 40cm

Dual power supply voltages are available on this unit, 115VAC for North America, 220VAC for Asia and Europe. The unit is preset at factory for using with 115VAC.







Features



1.This is the latest version of 300B output tube amp from Yaqin. Based on the previous version of MS-300B amp, MS-300C adds the external bias adjustment of 300B tubes and removes the speaker/earphone selecting switch on the rear panel.

2.Two 300B king tubes, pure Class A, and single-end integrated amplifier;

3.Tube rectifying and choke filtrations;

4.High DC voltage delay circuit to protect tubes;

5.Gold plated tube sockets;

6.Front headphone output for direct earphone listening;

7.Infrared remote control for volume adjustment and input selections;

8.Utilises the audiophile capacitors and high quality metal precision resistors dedicated for audio frequency;

9.Output transformers manufactured with Japanese silicon steel sheet and oxygen-free enamelled copper and high quality lacquer, which offer a wide dynamic range at full rated output;

10.Applies motor driven special potentiometer as volume controller with low noise, and durable and remote controllable;

11.Employs DC filaments power supply for 300B tubes to minimize humming noise;

12.Beautiful aluminium and steel heavy duty chassis, faceplate and bezels.





Packages:

A YAQIN MS-300C unit

A Power cable

A Remote control

Hex screw drivers to mount the cover cage and to adjust bias





YAQIN MS-300C Class A Stereo Single End Integrated Tube AmplifierYAQIN MS-300C Class A Stereo Single End Integrated Tube AmplifierYAQIN MS-300C Class A Stereo Single End Integrated Tube AmplifierYAQIN MS-300C Class A Stereo Single End Integrated Tube Amplifier
