Dayton DTA-100a Class-T Digital Amplifier 50 WPC - Description

Dayton DTA-100a Class-T Digital Amplifier 50 WPC - Description thumbnail-1
Dayton DTA-100a Class-T Digital Amplifier 50 WPC - Description photo-1
US$ 75 - 88 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Brand Name:
LEADAUDIO
Model Number:
LA-100
Type:
Home Amplifier
Contact Supplier Request Quote Chat Now
Shenzhen Longruixiang Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name LEADAUDIO
Model Number LA-100
Type Home Amplifier
Channels 2 (2.0)
Place of Origin Denmark

Specifications

Dayton DTA-100a Class-T Digital Amplifier 50 WPC - Description
100% quality guarantee

Dayton DTA-100a Class-T Digital Amplifier 50 WPC - Description

Dayton Audio's DTA-100a utilizes the Tripath TK2050 chipset that delivers 50W continuous power per channel (100W total) into an 8 ohm load. Class T amplifiers offer the audio fidelity of a Class AB amplifier while providing the power efficiency of a Class D design. The unit features a convenient front mounted 3.5 mm stereo input for quick connection of iPods, MP3 players, and other portable audio devices. A rear mounted RCA-type line level input is also provided for permanent connection of larger devices such as CD players. Speaker output connections are high-current banana plug receptacles spaced on 3/4" centers and compatible with standard double banana plugs (sold separately). High quality screw-on banana plugs that will accept 10~18 AWG wire are included. The DTA-100a also doubles as a high fidelity headphone amplifier that will drive any headphone easily, and delivers colossal sound stage and effortless dynamic range. The 1/4" stereo jack simplifies connection of larger home and studio style headphones. An adapter is also provided so smaller 3.5 mm personal-style headphones can be used. The amplifier comes complete with a world compatible power supply and its associated connectors.

Specifications:

*Power output: 2 x 50 watts RMS (into 8 ohms @ 3% THD), 2 x 30 watts RMS (into 8 ohms @ 0.01% THD)

*Frequency response: 20-20,000 Hz

*Efficiency: > 85%

*Dimensions: 2-1/8" H (including feet) x 3-3/8" W (at faceplate) x 5-1/2" D (including knob).

  • 50W per channel continuous into an 8 ohm load
  • Audiophile quality sound with less than 0.01% THD @ 30W
  • 1/4" headphone jack so unit can be used as a high fidelity headphone amplifier
  • Front-mounted 3.5 mm input for quick connection of portable audio devices
  • Compact extruded aluminum housing with thick black anodized faceplate
  • Rear mounted RCA type input for permanent connection of larger audio devices
  • Short circuit, thermal and overload protection
  • World compatible 24 VDC switch mode power supply included
