Home > Tools & Hardware > Hydraulic Parts > Hydraulic Cylinder > Synchronize Distributor Cylinder

Synchronize Distributor Cylinder

US$ 100 - 100 MOQ: 1 Set

Key Specifications

Get Latest Price

Standard or Nonstandard:

Standard

Structure:

Series Cylinder

Power:

Hydraulic

Contact Supplier Request Quote Chat Now

Yuci Changjin Hydraulics & Pneumatics Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Taiyuan

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard or Nonstandard Standard

Structure Series Cylinder

Power Hydraulic

Body Material Steel

Maximum Stroke 500

Place of Origin Shanxi, China

Specifications

Good Performance
High Accuracy
High ratio of performance to price

Synchronize distributor cylinder is a cylinder with a single rod and numbers pistons. All the pistons exactly have same stroke and speed. The synchronize distributor cylinder product has isometric (CJTBG) and non-isometric (CJTBGT) two series. All displacement and diameter of pistons are the same in CJTBG. They are different in CJTBGT.

The series can make the same or different type of single-acting, double-acting or swing cylinders completing the action at same time (hydraulic cylinders working from start to stop at same time).The CJTBG series cylinder added a check valve can also be used as a quantitative injector.

This series of synchronous precision is not affected by the system pressure, flux and load factors. According to the theory of synchronous distributor of hydraulic cylinder is a distributor can achieve complete synchronization, the function is to control valve, distributing valve or synchronous motor cannot achieve. Because of the synchronization error does not exist in principle, so the synchronization requirements at each branch of the hydraulic cylinder without the use of a variety of sensor, detection, tracking, and comparison, also need not use servo or proportion of higher price control system. Of course, if the requirements of synchronization of hydraulic cylinder are about speed, force, position and other parameters of the control requirements. Then you can use a built-in or external sensor for cylinders CJTBG. Synchronization control in large amount of leakage of hydraulic cylinder is not applicable to this series.
