thermal shock chamber
1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.
2.Excellent After sale Service:
18 months warranty. Besides, we can help you to repair your problem controller freely, even it's not from our factory. What you need to do is to send us the controller.
3.Commitment:
We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.
4.Good Packaging:
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
Advantages of top selling machine thermal shock chamber
top selling machine thermal shock chamber compared with peer's product:
top selling machine thermal shock chamber 's specification:
| Technical specification of cold and hot impact test chamber | |||||
| Model | SM-3P-A | SM-2P-A | |||
| System | Three-zone test by means of damper switching | Three-zone test by means of damper switching | |||
| Thermal recovery considitions | High temperature range | +60℃ to +200℃ | +60℃ to +200℃ | ||
| Ambient temperature range | +50℃ to +200℃ | +50℃ to +200℃ | |||
| Low temperature range | –70℃ to 0℃ | –70℃ to 0℃ | |||
| Ambient temperature range | –65℃ to 0℃ | –65℃ to 0℃ | |||
| Temperature. fluctuation | ±0.5℃ (±0.9°F) | ±0.5℃ (±0.9°F) | |||
| High temperature exposure:To +200°C | within 15min | 10min~ 15min | |||
| Normal temperature exposure | 5min -- 10min | ~ | |||
| Low temperature exposure:To-65℃ | 15min -30min | 30min | |||
| Temperature recovery time | within 10 min | within 5 min | |||
| Power supply | AC380V3 ø 4W 50 Hz | ||||
| Hot and cold impact test cases model specification | |||
| Model | inner size (W*H*D mm) | outside size (W*H*D mm) | weight(kg) |
| Two zone | |||
| SM-42-2P-A | 350*350*350 | 1450*1700*1480 | Approx.730 |
| SM-64-2P-A | 400*400*400 | 1500*1750*1530 | Approx.900 |
| SM-80-2P-A | 400*500*400 | 1500*1800*1530 | Approx.1050 |
| SM-100-2P-A | 500*500*400 | 1600*1800*1530 | Approx.1200 |
| SM-150-2P-A | 500*600*500 | 1600*1900*1630 | Approx.1420 |
| Three zone | |||
| SM-49-3P-A | 350*400*350 | 1550*1800*1600 | Approx. 860 |
| SM-80-3P-A | 400*500*400 | 1600*1900*1650 | Approx. 1050 |
| SM-100-3P-A | 500*500*400 | 1650*1900*1650 | Approx. 1050 |
| SM-150-3P-A | 500*600*500 | 1650*1980*1700 | Approx. 1150 |
| SM-200-3P-A | 650*460*670 | 1700*1900*1800 | Approx. 1 |
top selling machine Shippment of thermal shock chamber
Thank you for viewing this page, Bella wish you have a nice day! If you want more information about our top selling machine thermal shock chamber ,please contact Bella at:
Skype:climatic-chamber004
Email: sales4@climatic-chambers.(com.tw)
Web: Http://.tw
Http://sanwood.en.china.cn/
