Rain Environmental Test Chamber for Enclosure Water Resistance Test
Product Description
Equipment summary:
Rain Test Chamber: is used to test anti-rain and waterproof performance for products, the products such as .steam locomotive lamps, wiper performance, waterproof bands, motorcycle instruments, defense industry, navigation systems, missiles, radar cone top, aerospace industry, IEC IP code specifications that need an additional discussion.
Corresponding standard:
JIS D0203, D5500, SAE J585e, CNS 7138
Applicable industries:
Applied to plastics, rubber, paint, coatings, printing ink, paper, pharmaceuticals, food, cosmetics, textiles,
auto parts, packaging materials, building materials, electricity and the electrical products; it provide an important testing data for scientific research, product development and quality control
Techincal parameter:
| Rain Environmental Test Chamber Model | SM-LY-500C | SM-LY-1000C |
|
Studio size (D*W*H mm) |
800*800*800 | 1000*1000*1000 |
| Test bench area | Ø500mm | |
| The Pipe hole Size: | number 25 | |
| Put the tube aperture water | O 0.4mm (ordering instructions) | |
| Dripping bore spacing | 50mm; (can be adjusted according to customer requirements) | |
| Ring radius | 400mm | |
| The diameter of the spray pipe | Ø16mm; | |
| Swing angle | 0-270 degree (adjustable) | |
| Swing speed adjustment | 0-20 times (adjustable) | |
| Test bench speed | 0 ~ 20 /min (adjustable) | |
Rain Environmental Test Chamber Test time |
10min | |
Rain Environmental Test Chamber Test area |
400mm, the bearing capacity of 15Kg, 0 ~ 300mm adjustable shelves. (water jet to the sample distance) | |
| Rain water pressure | About 80Kpa | |
Rain Environmental Test Chamber Water supply |
According to the needs of regulation | |
Detailed Images
We have independent quality control department, each production process will pass through
the three test. If it is not qualified products, it will be returned to re-production.
Cost
Our Services
ALL OF OUR TEST CHAMBERS HAS ONE YEAR WARRANTY.
SANWOOD REPAIR THE EQUIPMENT IS UNDER THE ORDINARY USAGE AND ARISE ANY
HARDWARE PROBLEMS WHICH CAUSED BY PRODUCT ITSELF, RATHER THAN HUMAN
ERROR.
FIRSTLY, WE CAN PROVIDE THE SPARE PARTS WITH YOU. AND ALSO PROVIDE THE
SOLUTION ABOUT THE TROUBLE OF THE EQUIPMENTS.
SECONDLY, PLEASE SEND BACK THE EQUIPMENT, WHICH WILL BE REPAIRED BY OUR
COMPANY.
LASTLY, WE WOULD LIKE TO APPOINT OUR TECHNICAL ENGINEER TO YOUR COMPANY
TO REPAIR THE EQUIPMENT.
F A Q
1.Do you have any advantages in Rain Environmental Test Chamber?
SANWOOD has 8000 production bases in Dongguan, China. Factory direct sales, can reduce the cost of agency for you.
2.May I ask you how do you deliver Rain Environmental Test Chamber?
We have so many ways of Rain Environmental Test Chamber delivery, such as FOB, CIF,etc.
3.Is there a variety of language options for your operating system?
We use Korea SAMWON controller system, it has Russian, English, Chinese, Korean and other languages.
4. How long is the warranty period of your Rain Environmental Test Chamber ?
We provide free parts replacement service for resories with one year.
5. When will you give a respond if your Rain Environmental Test Chamber break down?
We will give you guidance by video conference when we receive your need of requirement.
