LGSJ-DBD-65 PP Strap Production Line
1,LGSJ65/28 extruder
Centre Hight 1000mm
Screw Speed 0~70r/min
1.1 Gear box
Harden Gear Jiangsu International
Reducer Model ZLYJ173
1.2 Screw barrel parameters
Screw diameter Φ65mm
L/D ratio 28/1
Screw and cylinder material 38CrMoAlA
Screw structure Mixing type
Heat treatment Nitriding treatment
Surface hardness HV940~1050
Nitriding depth 0.6~0.7mm
1.3 Screw tube heating, cooling parameters
Screw tube heating Infrared ray heat exchanger 3 period of 15KW
1.4 The main motor parameters
Speed adjustment mode Frequency control of motor speed
Motor power 15kw
1.5 Electric Control
Temperature control table CHINT
Low-voltage electrical CHINT
2, Extrusion Die
Vertical die 60mm
Heating power 1.5kw
3, Cooling box
Material Stainless stell
Specification 1000*300*300 mm(H*W*H)
4, First pulling
Roller specification φ130*100
Kind of drive Chain drive
Drive motor 0.75Kw Three-phase asynchronous motor
Speed adjustment mode Frequency control of motor speed
String speed 0~25m/min
5, Stretching oven
Length 2.3M (push-pull)
Temperature control Solid adjustment type temperature control
6, Embossing tensile machine
Roller specification φ150*100
Kind of drive Chain drive
Drive motor 3Kw Three-phase asynchronous motor
Speed adjustment mode Frequency control of motor speed
String speed 0~100m/min
7, Cooling box
Material Stainless stell
Specification 3000*300*300 mm(L*W*H)
8, Third pulling
Roller specification φ150*100
Kind of drive Chain drive
Drive motor 0.75Kw Three-phase asynchronous motor
Speed adjustment mode Frequency control of motor speed
String speed 0~100m/min
9, Winding
Drive motor 6-6N torque motor
Speed adjustment mode Electronic speed control
Paper pipe specification φ200 Paper core care circle
Winding width 9-19mm
10, Summary
Production 30~50Kg/h
