LGJD500/6000 high-speed tape machine
Product description:
1, is suitable for BOPP film coating.
2, the coating method: pneumatic control of the roll coating method.
3, automatic temperature control box, using the electric water tank (optional coal furnace).
4, the host variable frequency control system, before and after the synchronous design.
5, discharge use of magnetic brakes, to ensure uniform discharge tension.
Model |
LGJD500-6000 |
Oven length |
6M(a style) |
Voltage |
3P+1 380V/50HZ |
Heating |
Electric total power 16kw / Total coal heating power 2KW |
Maximum Maximum diameter of discharge |
600mm |
Maximum rewinding diameter |
250mm |
Minimum slitting width |
24mm |
Coating width |
500mm |
Coating speed |
20-30m/min |
Motor Powe |
1.1kw×2 |
Installation dimensions |
7.5×1.2×1.9m |
6, Rolling adopts magnetic clutch two-axis manual flip.
7, using the electronic correction device, make sure the edge of coated and finished neatly.
8, with a pneumatic pipe cutting machine, air compressor.
Main technical parameters:
Description of the required raw materials
BOPP film requirement: 500mm width, thickness 0.028mm, processing within the halo
Paper tube requirements: thickness 3mm (100 yards the following tape length) 5mm (100 yards or more tape length)
Glue: water-based pressure-sensitive adhesive solid content of 50% water
