Top Technology ps Foamed Sheet Extrusion Machine

Top Technology ps Foamed Sheet Extrusion Machine thumbnail-1
Top Technology ps Foamed Sheet Extrusion Machine photo-1
US$ 130,000 - 200,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Sheet
Plastic Processed:
Other, PSP
Contact Supplier Request Quote Chat Now
Laizhou Liangong Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Sheet
Plastic Processed Other, PSP
Screw Design Single-screw
Automatic Grade Automatic
Place of Origin Shandong, China
Brand Name LIANGONG
Model Number LGPSP-70/90
Voltage 380V
Power(W) 150KW
Dimension(L*W*H) 20mx2.5mx2.2m
Weight 10T
Certification CE/BV
After-sales Service Provided Engineers available to service machinery overseas

Top technology ps foamed sheet extrusion machine

Model: LGPSP-70/90

Equipment, detailed specifications (extruding output 2.5 tons / day):

1. First extruder

Screw diameter: ø70mm

Aspect Ratio: 32:1

Screw Material: 38CrMoAlA

Heat treatment method: nitriding treatment

Surface hardness: HV940 ~ 1050

 Nitriding depth: 0.6 ~ 0.7mm

 Surface treatment: polished after nitriding

 Barrel diameter: Φ140mm

 Barrel material: 38CrMoAlA

 Heat treatment: nitriding

 Surface hardness: HV940 ~ 1050

 Nitriding depth: 0.6 ~ 0.7mm

Gear-box form: horizontal square box

 Gear Material: 20GrMoTi

 Host Power: 37kw

 Motor Control: Inverter Control

 Temperature control cabinet: 6-zone automatic temperature control

 Butane pump: high-pressure pump 1 set butane (motor 2.2kw)

 Pressure Gauge: Digital Pressure Gauge 1

 Changer: Automatic hydraulic screen changer 1 set

 Electrical control cabinet: 1 set.

2. second Extruder

Screw diameter: ø90mm

L/D Ratio: 32 / 1

 Screw material: 38CrMoAlA

 Heat treatment: nitriding

 Surface hardness: HV940 ~ 1050

 Nitriding depth: 0.6 ~ 0.7mm

 Surface treatment: polished after nitriding

 Barrel diameter: Φ160mm

 Barrel material: 38CrMoAlA

 Heat treatment: nitriding

 Surface hardness: HV940 ~ 1050

 Nitriding depth: 0.6 ~ 0.7mm

 Gear-box form: horizontal square box

 Gear Material: 20GrMoTi

 Host Power: 37kw

 Motor Control: Inverter Control

 Temperature control cabinet: 6-zone automatic temperature control

 Electrical control cabinet: 1 set

 Head Pressure Gauge: 1

 Cooling: water cooling system, automatic control ---- 5 sets of cast aluminum heater

 Head Mold: 1 set

 Cooling setting: 1 set with split knife.

 Installation size extruder: 25X4X3m

3  cooling system

 Circulating water cooling hollow drum 1 set of stereotypes

 4, the traction system

   Rubber roller: 3 (according to customer's product needs to be installed)

 Diameter: 240mm

 Length: 1300mm

    Traction speed :3-31m / min

    Motor 1 set :4-3kw (Frequency Control)

 Traction device: 1 set

 Motor :4-3kw

 5, the winding device

 Winding width: 1.2 m

 Out of the device: automatically removed

 winding Scrolls: Pneumatic 2 pieces

 Winding Motor Type: YLJ112-6/10 torque motor 2 sets

 Worm Reducer: 2 - 80

 Static Elimination: 1 set

 Gas alarm: 1 set

6. The Mixing System

Hopper capacity 50kg / time (time relay control)

1 set 4 pole motor 3kw

7. Automatic feeding system

Automatic Control System

Motor:1.5kw-6, 1 set

8. Head Material: Die Steel

Sheet thickness 1.5-3mm

Sheet max. width: 1080mm

All of the above equipment for a complete set of Okada-type two-stage series foam PS sheet machine

Total installed power: 255kw

Center Height: 1000mm
