Help CenterHigh Quanlity Side-emitting 36w 600*600 Led Panel Light
Related Products
-
CE RoHS All Passed Side-emitting 36w 600 600 Led Panel Light With TUV CE & ROHSUS$ 10 - 50MOQ: 10 Pieces -
Led Panel Light 600*600mm 36w Vertical Emitting Panel LightUS$ 5 - 40MOQ: 10 Pieces
-
1.5m 40W LED Panel Light CEUS$ 5 - 40MOQ: 10 Pieces
-
1.5M LED Panel LightNegotiableMOQ: 1000 Pieces
-
ETL TUV36W 40W Led Square Panel ,600x600mm Panel Light,620x620mm Panel Light 36w 40w 48wUS$ 15 - 40MOQ: 10 Pieces
led square panel light
Feature:
* Main cooling structure using anodized aluminum and high transmittance acrylic light guide combination;
* Ultra-thin design, good lighting effects, but also brings a feeling of beauty;
* Uniform plane glow, illumination uniformity, soft light, comfortable but not bright, also can relieve eye fatigue;
* CRI above 80, finished luminous efficiency 75Lm / W;
* LED passed LM80 test, finished SCD <6;
*.Energy saved up to 50%, high intensity
*.3-year life span
* No electric wave
*. No such hazard that mercury or lead enters the environment
*. No RF interference
* CE certification
| Specification | YL-M6W36B-CE | YL-M6W36N-CE | YL-M6W36W-CE | |||
| Watt(W) | 36 | 36 | 36 | |||
| Lumens(lm) | 2700 | 2800 | 2900 | |||
| Beam Angle(deg) | 120 | 120 | 120 | |||
| CCT(K) | 2700 | 4000 | 6000 | |||
| CRI(Ra) | >80 | >80 | >80 | |||
| Energy Efficiency Classes | A+ | A+ | A+ | |||
| PF | ≥0.95 | ≥0.95 | ≥0.95 | |||
| Efficiency | >75 | >75 | >75 | |||
| Voltage(V) | AC100-240 | AC100-240 | AC100-240 | |||
| Frequency(Hz) | 50/60 | 50/60 | 50/60 | |||
| LifesPan(hrs) | 30000 | 30000 | 30000 | |||
| Working Temperature(°C) | -20~40 | -20~40 | -20~40 | |||
| Storage Temperature(°C) | -20~85 | -20~85 | -20~85 | |||
Applications :
*. Shop display windows, restaurants, hotels and other indoor decoration lighting; Exhibition hall, art room, museum, office, reading the local lighting; Night bars, card access, etc. KTV atmosphere lighting; Jewelry, silver jewelry and Fashion lighting;
*. Local lighting: Corridor, bathroom, garage, parking-lot lighting, factories, security lighting of residential area, indicating lighting, etc. Realized the Green Energy-saving environmental protection.
Our Certifications
Company View
FAQ
Q1: What is the Warranty for the lamps?
A1: For the lamps,we have 3 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.
Q2: What is colour temperature?
A2:shenzhen yili Electric offer lamps in warm, natural,pure and cool white with colour temperatures measured in Kelvin (K). The lower the colour temperature is, the warmer the light given by the LED:
- Warm white = 2700K-3200K
- Natural white = 4000K-4500K
- Pure white = 5000K-5500K
- Cool white = 6000K-6500K
Q3:: What is CRI?
A3: CRI is a figure which feedback the real objects colors.Higher CRI with higher cost.For LED tubes,the CRI is mostly 70-75Ra,and 80Ra with higher cost.But there are some suppliers write a high data to attract clients,please note.
Q4: Will your LED light bulbs work on a dimmer switch?
A4: We do not recommend using our LED light bulbs on a dimmer switch, this type of switch can potentially cause damage to the bulb.
Q5: What is the specific size of the screw base on your Edison base LED bulbs?
A5: The size is E-27/E-26. This size works in all common fixtures.
Q6: Why does my LED light bulb not work properly in extreme temperatures?
A6: Any temperature below 14 F or above 122 F may cause a LED bulb to flicker, dim, change color, or cease to function. Once the LED bulb is returned to an operational environment it should began to work properly.
Q7: What is the AC Voltage tolerance for our LED bulbs?
A7: Their AC voltage tolerance is +/- 10%.
Q8: Do your LED bulbs emit UV light?
A8: No. But you should never point an LED light into your eyes. The light is very bright and could cause damage.
Q9:Is there cheap shipping cost to import to our country?
A9: For small order,express will be best.And for bulk order,sea ship way is best but take much time.
For urgent orders,we suggest via air to airport plus our ship partner send to your door.
Q10:Can we get support if we have our own market position?
A10: Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.
Why Choose us?
1. Your inquiry related to our products or prices will be replied in 24hours.
2. Well-trained and experienced staffs to answer all your inquiries in fluent English
3. OEM&ODM, any your customized lightings we can help you to design and put into product.
4. Monthly output over 10, 000PCS. Single package in Gift Boxes.
6. 100% QC inspection Before Shippment, CE/UL/FCC listed,competitve price
To establish an outstanding enterprise platform by using the best attitude,we are committed to offering service for our clients,helping staffs and devoting for shareholders, so as to creat social value which exceeds commerce value
