HDT5120THB Truck-mounted Concrete Pump for Sale
TLS(Iron Giant) Brand, Famous Trademark of China
CCC/ISO9001 Certified
I.Brief Introduction to Truck-mounted Concrete Pump
Adopting the special chassis for FAW JIEFANG-brand heavy-duty truck, looking elegant and unique, comfortable to drive, strong in horsepower, low in oil consumption, reliable and durable in performance.
The power system which adopts the world-famous 6-cylinder German DEUTZ diesel engine (or China’s famous-brand electric motor) has stable and reliable performance. Equipped with the auto throttle, the engine shows an economical efficiency of fuel consumption.
The hydraulic system adopts the German REXROTH oil pump and the American VICKERS control valve, which match perfectly and have higher efficiency.
The main electric components of the PLC computer control system are brand products made by SIEMENS, LG, SCHNEIDER and so on.
All operations can be carried out by short-distance control and wired remote control. The wired remote control and the control box, which are two separate operating devices, ensure the reliability and safety of the equipment.
The S-shaped reversing valves, hard alloy eyeglass plates and cutting rings, rubber springs which can automatically compensate the clearances between end faces all ensure a proper sealing property.
The mixer can rotate forward or backward and the rotating speed can be regulated so that the problem of aggregate blocking can be settled in time.
The big-diameter conveying cylinder has a strong suction ability and can afford large pumping flow. The pumping capacity can be regulated through the stepless control device to get different outputs.
The equipment has such functions as positive pumping, negative pumping and touch-move. The conveying pipe is easy to clean and the concrete piston is very convenient to change.
The high-pressure cleaning system makes vehicle cleaning simple and easy.
The automatic lubrication of the hopper and the concrete cylinder makes the pumping work smooth and easy.
The sealing parts of the main oil cylinder are made by PARKER Company of the US, and the inside of the concrete cylinder is covered with a thickened chromium coat, which ensures that 20,000 m³ of concrete can be successfully pumped without any problems.
The patented design of the high-low-pressure switch valve can greatly reduce the fluid resistance in the main hydraulic system and improve the system’s effective power by 20%.
II.Main Technical Parameters of Truck-mounted Concrete Pump
Items |
Description |
Unit |
Parameters |
Parameters of the Whole Truck |
Product Model |
HDT5120THB |
|
Overall Dimension (L*W*H) |
mm |
8820×2460×2990 |
|
Full-load Total Weight |
kg |
12364 |
|
Max. Traveling Speed |
km/h |
107 |
|
Min. Turning Radius |
m |
18 |
|
Max. Grade Ability |
% |
37 |
|
Approach Angle |
. |
22 |
|
Departure Angle |
. |
15 |
|
|
Main Parameters of the Pumping System |
Diesel Engine Model |
BF6M1013C |
|
Emission Standard |
European III |
||
Max. Engine Power |
kW |
161(2300r/min) |
|
Oil Consumption |
g/kW.h |
210 |
|
Main System Pressure |
MPa |
32 |
|
Hydraulic Oil Cooling Mode |
Wind cooling |
||
Theoretical Concrete Output |
M3/h |
90 |
|
Theoretical Concrete Pressure (high/low) |
MPa |
12/8 |
|
Pumping Times(high/low) |
times/min |
13/23 |
|
Rated Vertical Delivery Height |
m |
180 |
|
Rated Horizontal Delivery Distance |
m |
500 |
|
Delivery Pipe Diameter |
mm |
Φ125 |
|
Feeding Bucket Volume |
L |
0.65 |
|
Feeding Height |
mm |
1350~1450 |
|
Slump |
cm |
14~23 |
|
Max. Aggregate Size |
mm |
40 |
|
Distributing Valve Mode |
S-Valve |
||
Water Tank Volume |
L |
600 |
|
Lubricating Mode |
Self-lubricating |
||
Main Technical Parameters of the Traveling System |
Chassis Model |
JIEFANG CA1126P1K212 |
|
Wheel Base |
mm |
4700 |
|
Engine Model |
CA6DE1-18 |
||
Emission Standard |
European III |
||
Max. Engine Power |
kW |
132(2600r/min) |
|
Max. Engine Torque |
N.m |
559(1500~1700r/min) |
|
Cylinder Diameter × Stroke |
102mm×1200mm |
||
Displacement |
L |
5.88 |
|
Compression Ratio |
17.5:1 |
||
Oil Consumption within 100 kilometers |
L |
17.3 |
|
Oil Tank Capacity |
L |
160×2 |
III.Detail Pictures of Truck-mounted Concrete Pump
IV.Introduction to Our Company
Our main products cover 12 series with more than 80 varieties, such as:
1. Tower Cranes (3T-25T, stationary, mobile, outside-climbing, inside-climbing, horizontal-jib, luffing-jib, hammer-head, flat-top, multi-speed, stepless-speed);
2. Construction Elevators (multi-speed, stepless-speed);
3. Concrete Mixers (rotary-drum-type, double-horizontal-shaft);
4. Concrete Batchers;
5. Concrete Mixing/Batching Plants (25-480m3/h, stationary, mobile, conventional-type, compact-type, simple-type, commercial-type);
6. Concrete Truck Mixers (6-16m3);
7. Truck-mounted Concrete Pumps (diesel, electric);
8. Trailer-mounted Concrete Pumps (diesel, electric);
9. Concrete Pump Trucks (with 24-52m booms);
10. Asphalt Mixing Plants (40-320t/h, stationary, mobile, oil-burning, gas-burning, coal-burning);
11. Stabilized Soil Mixing Plants;
12. Rotary Drilling Rigs...
Quality Control (QC)
Third Control
ISO9001:9001 Certificate
European Certificate
Enviroment Protection Design
Corporate Culture
ENTERPRISE TENET: All for clients, all from clients.
ENTERPRISE GOAL: Try our best for perfectness.
BUSINESS PRINCIPLE: Focusing on people first, Doing business honestly, Sticking to win-win development firmly.
BUSINESS POLICY: Arming engineering machinery with high technology, Upgrading traditional industry with high quality, Promoting the updating of traditional industry with all our efforts.
CULTURE SPIRIT: Never complain, always look for a better way, always prepare to get a chance. Innovation is essential to the development of an enterprise and even a nation. Every one of HONGDA Group is an image ambassador of our enterprise, To be an upright person in all seriousness,to be a good worker without ostentation.
