Help CenterJCX840&900-B1, Glazed Tile and IBR Double-layer Roof Metal Sheet Roll Forming Machine
Related Products
-
JCX-80-300mm/60-200mm-O1, Mitsubishi PLC Hydraulic Cutting Downspout Pipe Forming MachineUS$ 10,000 - 30,000MOQ: 1 Set -
JCX-80-300mm/60-200mm-I1, Mitsubishi PLC Hydraulic Cutting Downspout Pipe Forming MachineUS$ 10,000 - 30,000MOQ: 1 Set
-
JCX-80-300mm/60-200mm-L1, Mitsubishi PLC Hydraulic Cutting Downspout Pipe Forming MachineUS$ 10,000 - 30,000MOQ: 1 Set
-
, Mitsubishi PLC Hydraulic Cutting Downspout Pipe Forming MachineUS$ 10,000 - 30,000MOQ: 1 Set
-
JCX840&900-E1, Glazed Tile and IBR Double-layer Roof Metal Sheet Roll Forming MachineUS$ 10,000 - 30,000MOQ: 1 Set
Specifications
High quality;Warranty: 1 year;
If necessary, engineers available to service machinery overseas;
TUV Certification
Processes: Man-made uncoiler—Roll forming machine—PLC system—Hydraulic system-Blade—Receiving table
Specifications:
No. |
Item |
Description |
1 |
Suitable material |
Color steel sheet ,galvanized steel sheet, Aluminium sheet |
2 |
Working speed |
1-3m/min & 8-15m/min |
3 |
Main motor power |
4kw with cycloidal reducer |
4 |
Hydraulic station power |
5.5kw |
5 |
Electrical control system |
PLC control system with famous brand |
6 |
Thickness of material |
0.25mm~0.8mm |
7 |
Shaft diameter |
70mm |
8 |
Roller station |
13 stations & 13stations |
9 |
Material expand axis |
1000mm/1200mm/1220mm/1250mm |
10 |
Dimension |
6500x1500x1500mm |
11 |
Driving mode |
Chain |
12 |
Electric tension |
380V 3phase 50HZ or as the customer's requirements |
|
13
|
Material of roller |
High grade 45# forged steel plated with hard chrome plating |
14 |
Material of cutting |
Cr12 mould steel with quenched treatment |
15 |
Working time |
Can be 24 hours |
16 |
Workers |
1-2 only |
Our Machine's Advantage
Seaworthy Packing:
We provide the technical support for whole life.
Meanwhile, if any parts go broken and not artificial damage, we will send you new ones for free.
When need the technician to go abroad, we will arrange the technician.
Minimum Order Quantity: |
1 |
Price: |
negotiable |
Packaging Details: |
seaworthy packing |
Delivery Time: |
30 days |
Payment Terms: |
T/T, LC, CASH ETC |
Supply Ability: |
30 Sets per month |
