Ceiling Suspension System/ Stud and Track
US$ 700 - 800
MOQ: 500 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HY
Model Number:
Q195
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Ceiling Suspension System/Main Channel and Furring Channel/ Light Steel KeelUS$ 700 - 800MOQ: 500 Kilograms -
Ceiling Suspension System/Main Channel and Furring Channel/Omega Light Steel KeelUS$ 700 - 800MOQ: 500 Kilograms
-
Ceiling Suspension System/Main Channel and Furring Channel/ Stud and TrackUS$ 700 - 800MOQ: 500 Kilograms
-
Gypsum Board Partition & Galvanized Steel Stud PriceUS$ 0.1 - 1MOQ: 10 Tons
-
50 Drywall Metal Stud/galvanized Steel Profiles for GypsumUS$ 0.1 - 1MOQ: 10 Tons
Place of Origin
Jiangsu, China
Brand Name
HY
Model Number
Q195
Material
Galvanized Sheet
Specifications
Main channel and furring channel
1.used for ceiling suspension system
2.size precision
3.good quality
4.different size
Ceiling suspension system/Main channel and furring channel
Main date
| item name | main channel |
| size | 38*10mm |
| thickness | 0.40,0.45,0.50,0.55,0.60,0.80,1.0mm |
| length | 2400mm, 3000mm, 3600mm, 4800mm |
| package | 20pcs/bundle |
| technology | Dot, ribbed, or based on client's requirement |
| standard | GB11981-2001 |
Feature
1.Light weight, high strength, safely.
2.High zinc coating, moistureproof, fireproof,
3.Earth-quake resistance, keeps the temperature constant .
4.Durable, long time life.
5.Recyclable, environment friendly.
Specification for main product
| commodity | size (mm) | thickness (mm) | length (mm) | pack |
| Australia system | ||||
| Primary cross rail | 25*21 | 0.55, 0.75,0.85,1.0 | 3600, 4800 | 10 |
| Furring channel | 28*38 | 0.55, 0.75,0.85,1.0 | 3000,3600,4800 | 25 |
| Wall track | 26*16*26 | 0.45,0.55,0.75 | 3000 | 20 |
| Angle | 30*30 | 0.55, 0.75 | 3000 | 50 |
| Stud | 51*35.5 | 0.55, 0.75 | 2400,3600,4800 | 10 |
| 64*35.5 | 0.55, 0.75 | 2400,3600,4800 | 10 | |
| 76*35.5 | 0.55, 0.75 | 2400,3600,4800 | 10 | |
| 92*35.5 | 0.55, 0.75 | 2400,3600,4800 | 10 | |
| Track | 51*32 | 0.55, 0.75 | 3000 | 10 |
| 64*32 | 0.55, 0.75 | 3000 | 10 | |
| 76*32 | 0.55, 0.75 | 3000 | 10 | |
| 92*32 | 0.55, 0.75 | 3000 | 10 | |
| Middle East system | ||||
| Main channel | 38*10 | 0.45,0.50,0.60,0.80,1.0 | 2400,2950,3600 | 20 |
| Furring channel | 68*35*12 | 0.40,0.45,0.50,0.60 | 2400,2950,3600 | 25 |
| Edge channel | 25*25 | 0.35,0.40,0.45,0.50 | 3000 | 50 |
| Stud | 50*34.5 | 0.40,0.45,0.50 | 3000,3600,4800 | 10 |
| 70*34.5 | 0.45,0.50,0.60 | 3000,3600,4800 | 10 | |
| 75*34.5 | 0.45,0.50,0.60,0.70 | 3000,3600,4800 | 10 | |
| 100*35 | 0.50,0.60,0.70,0.80,1.0 | 3000,3600,4800 | 10 | |
| Track | 52*25 | 0.40,0.45,0.50 | 3000,3600,4800 | 10 |
| 72*25 | 0.45,0.50,0.60 | 3000,3600,4800 | 10 | |
| 76*25 | 0.45,0.50,0.60,0.70 | 3000,3600,4800 | 10 | |
| 100*25 | 0.50,0.60,0.70,0.80,1.0 | 3000,3600,4800 | 10 | |
| East Europe system | ||||
| CD | 60*27 | 0.40,0.45,0.50,0.60,0.80 | 2800,3000,3600 | 12 |
| UD | 28*27 | 0.40,0.45,0.50,0.60,0.80 | 2800,3000,3600 | 20 |
| T-type keel | 20*6 | 0.35,0.40,0.45 | 2400,3000,3600 | 50 |
| 24*10 | 0.35,0.40,0.45 | 2400,3000,3600 | 50 | |
| Stud (CW) | 50*50 | 0.40,0.45,0.50,0.60,0.80 | 2800,3000,3600 | 10 |
| 70*50 | 0.40,0.45,0.50,0.60,0.80 | 2800,3000,3600 | 10 | |
| 75*50 | 0.40,0.45,0.50,0.60,0.80 | 2800,3000,3600 | 10 | |
| 100*50 | 0.40,0.45,0.50,0.60,0.80,1.0 | 2800,3000,3600 | 10 | |
| Track (UW) | 52*40 | 0.40,0.45,0.50,0.60,0.80 | 2800,3000,3600 | 10 |
| 72*40 | 0.40,0.45,0.50,0.60,0.80 | 2800,3000,3600 | 10 | |
| 75*40 | 0.40,0.45,0.50,0.60,0.80 | 2800,3000,3600 | 10 | |
| 100*40 | 0.40,0.45,0.50,0.60,0.80,1.0 | 2800,3000,3600 | 10 | |
Install:
Case:
package:
Certificate:
