Atlas Good Traits VFC Screw Air Compressor

Atlas Good Traits VFC Screw Air Compressor photo-1
Atlas Good Traits VFC Screw Air Compressor photo-2
Atlas Good Traits VFC Screw Air Compressor photo-3
Atlas Good Traits VFC Screw Air Compressor photo-4
Atlas Good Traits VFC Screw Air Compressor photo-5
Atlas Good Traits VFC Screw Air Compressor photo-6
US$ 3,000 - 50,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Type:
Screw
Configuration:
Stationary
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Screw
Configuration Stationary
Power Source AC Power
Lubrication Style Lubricated
Mute Other, Low Noise
Place of Origin Shanghai, China
Brand Name Bolaite (Atlas Copco)
Model Number BLT-40A VFC
Voltage 220V/380V/400V/415V/440V/ and others
Dimension(L*W*H) 1100*865*1380
Weight 585
Certification ISO,CE,ENERGY SAVING CERTIFICATE
Warranty one year for the whole machine
After-sales Service Provided Overseas service center available

Packing details:Standard Wooden case packing for shipment

                         Email:rita AT atlaschina DOT cc

                         Skype:ritaatlas

                         What's App:+86 152 2182 9074

                         Website:

           2015 Atlas Good Traits VFC Screw Air Compressor

-----------------------Better life together------------------------



Company Information

 Atlas Good Traits VFC Screw Air Compressor

Bolaite(shang hai) Compressor Co.,Ltd.was established in 1998.

It is mainly engaged in designing,producing,and selling double screw air compressors.

Bolaite(shang hai) Compressor Co.,Ltd.is wolly-owned by Atlas copco,

belong to Atlas copco Group Compressor Technology(CT).

Division new factory with total investment of $250,000,000.00

Lloyd’s certificates:ISO4001,OHSAS18001,ISO9001.

It is located in Jia Ding district, shang hai ,covering an area of 9,000 square meters.

Products has been sold all over the word,especially the global market,





Technical Parameter- Atlas Good Traits VFC Screw Air Compressor

Model



BLT-40A VFC

Free Air Delivery

M3/min

4.75

4.50

4.25

3.75

Working Pressure

bar

7

8

10

13

Compression stage



Single stage compression

Cooling model



Air cooling

Discharge temperature

≤The environment temperature +15℃

Noise Level

dB(A)

65±2

Transmission mode



Belt transmission

Voltage

V/Ph/Hz

380V/3Ph/50Hz

Motor power

KW/HP

30/40

Starting model



 Variable Frequency starting

External dimensions

L

mm

1100



W

mm

865



H

mm

1145

Weight

Kg

465

Exhaust Pipe diameter

inch

G1



Remarkable components supply chain.

No.

Parts Name

Quantity

Brand

1

Air end

1pc

Atlas Copco from Belgium

2

Bearing

1pc

Sweden SKF

3

Air inlet valve

1pc

Atlas Copco

4

Electric motor

1pc

ZODA

5

Thermostat valve

1pc

Atlas Copco

6

Pressure sensor

1pc

Denmark Danfoss

7

Air filter

1pc

Atlas Copco

8

Oil filter

1pc

Atlas Copco

9

Oil and gas separator

1pc

Atlas Copco

10

Minimum pressure valve

1pc

Atlas Copco

11

Electric system

1pc

Siemens

12

High pressure hose assembly

1pc

Italy MANULI



 European Production Line- Atlas Good Traits VFC Screw Air Compressor

Atlas Good Traits VFC Screw Air Compressor



Finished Air Compressor- Atlas Good Traits VFC Screw Air Compressor Atlas Good Traits VFC Screw Air CompressorAtlas Good Traits VFC Screw Air CompressorAtlas Good Traits VFC Screw Air Compressor

Standard export packing- Atlas Good Traits VFC Screw Air Compressor

Atlas Good Traits VFC Screw Air CompressorAtlas Good Traits VFC Screw Air CompressorAtlas Good Traits VFC Screw Air Compressor

  Film+Carton+wooden case standard export package. we will install and test the machine for you before shipping, you just need to connect power supply.



 FAQ for your reference-  Atlas Good Traits VFC Screw Air Compressor

1.Payment terms

T/T (Telegraphic Transfer) or Western Union or L/C at sight



2.Delivery date

Based on order quantity, generally it takes 3 days for production.



3.Shipping way

Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air

Bulk order: we suggest by air or by sea.



4.Quality control

We have our own experienced QC.

There will be strict inspection and testing for every order before shipping out.



5.After-sales

A. Our sales team will response for your question within 24 hours (Holidays Excluded)

B. Technical Support will be available at any time.
