Atlas 90KW Variable Frequency Screw Air Compressor

Name: Atlas 90KW Variable Frequency Screw Air Compressor
Brand: Bolaite (Atlas Copco)
SKU: 125611667

US$ 5,000 - 50,000 MOQ: 1 Piece

Key Specifications

Condition:

New

Type:

Screw

Configuration:

Stationary

Shanghai Desirable Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Screw

Configuration Stationary

Power Source AC Power

Lubrication Style Lubricated

Mute Other, Low Noise

Place of Origin Shanghai, China

Brand Name Bolaite (Atlas Copco)

Model Number BLT-120A VFC

Voltage 220V/380V/400V/415V/440V/ and others

Dimension(L*W*H) 1935*1170*1796

Weight 1550

Certification ISO,CE,ENERGY SAVING CERTIFICATE

Warranty one year for the whole machine

After-sales Service Provided Overseas service center available

Specifications

Atlas 90KW Variable Frequency Screw Air Compressor :
1>CE Approved
2>Atlas copco Air End
3>Double screws
4>Cheap

BLT-120A VFC Atlas 90KW Variable Frequency Screw Air Compressor :

1. Air compressor features:

Atlas BolaiteCompressors Features	Pictures	Source
1. Atlas Copco Bolaite Air End: > Rotor Technique, > Patent Molded Lines, enlarge efficiency. > High-Rigidity rotor, extend host life cycle.		Sweden Atlas Origin
2.High Quality Motor: >Efficency motor, IP54		ABB WOLONG
3.Simplicity of operator: >PLC control platform >Intelligent automation control and the self-failure diagnosis system realize unattended.		Schneider Electric France Origin
4.Oil-gas Separator: >Three stage oil air separate design,lower power consumption.		Germany MANN Origin
5.High efficiency Air Filter: >In normal environment, dedusting 99.9%.		Germany MANN Origin

2. Air compressor speicifications:

Model			BLT-120A VFC/90KW
Air discharge Pressure discharge	M³/min/Mpa		6.84-17.1/0.7
			6.76-16.9/0.8
			5.84-14.6/1.0
			5.04-12.6/1.3
No of compression stage			Single stage compression
Cooling model			A-Air cooling W-Water cooling
Discharge temperature	°C		≤The environment temperature +15°C(Air cooling) ≤40°C(Water cooling)
Noise Level	dB(A)		72±2
Transmission mode			Belt transmission
Power supply	V/Ph/Hz		As your inquiry
Motor power	kw		90
Stating model			Y- Transformation Start
External dimensions	L	mm	1935
	W	mm	1170
	H	mm	1796
Weight	Kg		907
Exhaust pipe diameter	inch		G 2”
Inlet pipe diameter	inch		G 1”
