Help CenterAtlas Copco(Bolaite) 100hp Heavy Duty Air Compressor for Hot Sale
Related Products
-
Atlas Copco(Bolaite) 75hp Screw Air Compressor Distributor in AlgeriaUS$ 8,000 - 35,000MOQ: 1 Set -
Atlas Copco(Bolaite)45kw Screw Air Compressor Supplier in ShanghaiUS$ 8,000 - 35,000MOQ: 1 Set
-
Atlas Copco Bolaite ISO9001 Screw Air CompressorUS$ 1,000 - 10,000MOQ: 1 Piece
-
Atlas Copco (Bolaite) 75hp Screw Compressor With High Quality AirUS$ 6,000 - 83,500MOQ: 1 Set
-
Atlas Copco (Bolaite) Low Price Screw Air Compressor 55kwUS$ 6,000 - 83,500MOQ: 1 Set
Specifications
heavy duty air compressor1.Air end-Atlas Copco
2.Motor-ZODA
3.Motor power:75kw/100hp
4.High efficiency screw compressor
Atlas Copco(Bolaite) 100hp heavy duty air compressor for hot sale
1.Durable -Air end from origin Atlas Copco
2.High competitive price - high quality design with low cost
3.Perfect after-sales service - 24 hours online, within 1hour answer your inquiry and TM
4.Wholly-owned by Atlas Copco Group - supply professional and suitable solutions for you
5.More than 50 factories all over the world,China has the largest factory all of them
6.The factory is located in Shanghai,it takes about 90mins from PVG airport.
It's very convenient for you to visit our compressor factory.
High quality configuration of heavy duty air compressor
Parts |
Brand |
Air End |
Atlas Copco |
Intake Valve |
Hoerbiger (Austria) |
Solenoid Valve |
CEME (Italy) |
Temperature Sensor |
Hoerbiger (Austria) |
Pressure Sensor |
Huba Original (From Switzerland) |
Motor |
Qingjiang Motor |
Coupling |
Germany KTR |
Thermostat Valve |
Italy VMC |
PLC |
Schneider Electric (France), SIEMENS |
Minimal Pressure Valve |
Hoerbiger (Austria) |
Air Filter Element |
Germany MANN |
Oil Filter Element |
Germany MANN |
Oil Separator Element |
Germany MANN |
Bearing |
Sweden SKF |
Technical parameter of heavy duty air compressor
Model |
|
BLT-100A/W |
||||
Free Air Delivery |
M3/min |
13.5 |
13.00 |
11.8 |
10.00 |
|
Working Pressure |
bar |
7 |
8 |
10 |
13 |
|
Compression stage |
|
Single stage compression |
||||
Cooling model |
|
Air cooling |
||||
Discharge temperature |
℃ |
≤The environment temperature +15℃ |
||||
Noise Level |
dB(A) |
62±2 |
||||
Transmission mode |
|
Belt transmission |
||||
Voltage |
V/Ph/Hz |
380V/3Ph/50Hz |
||||
Motor power |
KW/HP |
75/100 |
||||
Starting model |
|
Star-delta starting |
||||
External dimensions |
L |
mm |
1585 |
|||
|
W |
mm |
1170 |
|||
|
H |
mm |
1800 |
|||
Weight |
Kg |
1260 |
||||
Exhaust Pipe diameter |
inch |
G 2” |
||||
Products advantages of heavy duty air compressor
Item |
Description of parts |
Advantages of stationary air compressor |
1 |
Air end |
Atlas Copco air end,stable and reliable, lower energy consumption. |
2 |
Air filter |
Original efficient filter; Dust effect of 99.9%; Ensure effective dust compressor Filtration efficiency "3 microns." |
3 |
Vacuum loading and unloading valve |
Low pressure drop No large and heavy spring Simpler, less parts, maintenance |
4 |
Motor |
Efficient motor, IP54 protection, F class insulation, can work even in harsh environments |
5 |
Belts |
Belt adopts the world's top brands, high driving accuracy, good stability, long service life. |
6 |
Oil filter |
Imported oil filter, new 10 micron level (industry standard: 30 micron), better protection of air end. |
7 |
Pipeline |
import high-temperature materials hose, long-term operation without leakage. |
Our office in Shanghai
Cutting Workshop
Large models workshop
Testing Workshop
Applied industies
AC CEO Visit Bolaite factory in Shanghai
Packing for Air compressors
How to serve for you?
• Inquiry: Contact us by email, phone call, fax, Instant Messenger (Trade manager, MSN, Skype) and let us know your inquiry.
• Discussion: Specify the items you desire, confirm specification;
• Quotation: Prices offered and accepted.
• Place order as per contract or discussion.
• Perform invoice( sales contract ) In duplicate confirmed and kept by both sides.
• Payment settled.
• Order completed under our arrangement.
• Goods shipped as per contracted term.
• Goods arrive at local port or warehouse, depending on contracted term.
• Support & re-ordering.
FAQ(Frequently Asked Questions),to provide you a suitable model,pls confirm:
1.Working pressure(bar/Mpa/psi)?
2.Air delivery(CFM/m3/min)?
3.What's the compressor used for?
4.Voltage in your couontry(V/PH/HZ)?
5.A whole equipment includes: air compressor,air dryer,air filters and air tank.
Any need,pls don't hesitate to contact us! Let's make better life together!
