Cold storage room for Hotel and Restaurant
Cold storage room Product Feature
1. The Cold storage room panel is durable in use, color lasting & coated layer keeping.
2. It is made with Bayer polyurethane material by high pressure foaming. The cold room panel density is up to 40kg/m3 or above.
3. The internal cold room floor panel of our cold room is made by 1.0mm galvanized steel and durable for anti-scratch.
4. The hinged door panel of our coldroom is made by heavy duty door hinge, heavy duty door lock and hydraulic door closer.
5. The connection of our cold room panels are made with PE sealing rubber which is with high quality sealing.
6. The connection of our cold room is with cam lock construction and excentric fasterners for tight connection and sealing of the cold room
Cold storage room Product information:
Dimension |
Length (m) *Width (m)*Height (m) According to client's requirement . |
Panel |
polyurethane insulation panel,43kg/m3, fire retardant |
Foaming material |
BASF |
Panel thickness |
50mm,75mm,100mm,150mm,200mm |
Steel cover |
stuccom embossed aluminum,painted galvanized steel,stainless steel,PVC stell |
Panel connection |
cam lock type, use hexagonal key to assemble and disassemble |
Type of door |
hinge door, convex door, sliding door |
Temp.of room |
-45~+20 degree, optional |
Purpose of cold room |
fruit,vegetable,flower,fresh/frozen meat etc |
Refrigeration unit |
Copeland / Bitzer / Sanyo etc |
Refrigeration type |
air cooled / water cooled |
Fittings |
all necessary fittings are included, optional |
Place to assemble |
indoor/out door(concrete construction building/steel construction building) |
Voltage |
220V/50HZ, 220V/60HZ, 380V/50HZ optional |
we are a professional manufacturer,which help our clients to customize the Cold storage room . Pls answer us the your detailed requirement. Tks!
1. What's the Cold storage room size you require ? (such as the width , length , height )
2.what's the Cold storage room inner temperature you require ?
3.what kind of food you will store into the Cold storage room ?
4. what kind of door for the Cold storage room you require ?
5. what's the voltage/ frequency for the frequency you require ?
6.The panel surface is covered of the steel sheet. The steel sheet optional: painted galvanized steel,embossed stucco aluminum, stainless steel. Which one you like ?
7.what's the ambient temperature in your local country ?
Cold storage room Inner can install the shelf
plastics-dipping shelf (5 pcs/set) (L:726*W:600mm)
Cold storage room door
hinged door/glass door/maunal/electric sliding door
size can be changed according to the client's requirement
| No | Door type | door size | door heater voltage |
| 1 | Flush door | 800mm W*1900mm H | 24V / 36V |
| 2 | not flush mounted hinged door | 832mm W*1860mm H | 24V / 36V |
| 3 | sliding door | 832mm W*1860mm H | 24V / 36V |
The door can install the Temperature indicator
Cold storage room panel:
| No. | Inspection Item | Unit | Technology requirement | Inspection result |
| 1 | Density | kg/m3 | 32~50 | 43 |
| 2 | Compressing strength(10%deformation) | Kpa | ≥ 160 | 200 |
| 3 | Bending Stregth | Kpa | ≥ 245 | 331 |
| 4 | Absording rate | % | ≤ 4 | 3 |
| 5 | Heating coefficient | W/m.k |
0.024 | 0.021 |
| 6 | Average burning time(vertical) | S | ≤ 30 | 3 |
| 7 | Average burning height(vertical) | s | ≤ 250 | 250 |
Every panel is male (convex) and femal(concave) type,cam locks are pre-burried inside the panels,use a key to lock them together.
our panel advantage
1. Our panel foaming material is Italy Brand BASF . The whole panel average density above 40kg/m3 which enable the panel with better thermal conductivity of 0.021W/(m.k). The national standard is 0.024W/(m.k), which mean our panels will save the energy consumption of 12.5% than national standard
2.All the panels we produce are with fire retardant, self-Extinguish, Fireproofing Grade is B1. It refers to the safety problem.
3.The steel sheet we purchase from Baosteel and POSCO which are the biggest steel factories in the world, they promise the painted galvanized steel they produce will not fade in 15~20 years.
4. Gasket is around the edge of each Cold storage room panel , when panel lock together,the cool air will not leak,and the hot air can not come in .It enable the cold room with better air-tightness. So our panel is with excellent thermal insulation effect . It can save much more energy consumption.
Cold storage room condensing units: (Integrative Unit)
ZANOTTI
Feature:
1. Adopt inpotred Hermetic piston type compressor
2. Imported branded MAVIB,EBM Fan
3. Capillary expansion system , Refrigerant Gas R404a
4. Intelligent automatic defrosting system ,which can save much more energy consumption.
Our compressor is with Defrost sensor,which decide the defrost time automatically . So it can reduce the energy consumption .
5.easy to install , just need to hang on the wall
Fan for Cold storage room
production line for our Cold storage room
Package for our Cold storage room
Some of our Cold storage room Project :(Domestic and Overseas )
Take part in the Exhibition every year
