Home > Industrial Equipment & Components > Refrigeration Equipment > Cold Room > PU Insulated Cold Rooms and Freezer Rooms With Cam Lock System
PU Insulated Cold Rooms and Freezer Rooms With Cam Lock System
US$ 28 - 39
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Temperature:
-18 / -5 degree C
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Foshan China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
10ton Seafood Cold Store With Grey-painted Galvanized SteelUS$ 28 - 39MOQ: 1 Square Meter -
25 CBM Modular Standard Cold RoomUS$ 27 - 35MOQ: 2 Square Meters
-
Food Freezer RoomUS$ 27 - 45MOQ: 210 Square Meters
-
Modular Cold Storage With Polyurethane InsulatedUS$ 28 - 39MOQ: 1 Square Meter
-
Model DCWF-10 Modular & Standard Cold RoomUS$ 28 - 39MOQ: 1 Square Meter
Condition
New
Temperature
-18 / -5 degree C
Place of Origin
Guangdong, China
Brand Name
Dachang
Model Number
DCWR-40
Voltage
110V/220V
Power(W)
Above 1900
Dimension(L*W*H)
3549mm*5915mm*2300mm
Weight
Above 500kg/room
Certification
ISO9001:2008
Warranty
1 year
After-sales Service Provided
Overseas third-party support available
PU Insulated cold rooms and freezer rooms with cam lock system
Product Description
1.Production Information- standard modular cold rooms and freezer rooms
| Model | DCWF-40 | DCWR-26 |
| Refrigeration storage volume(m3) | 40 | 40 |
| Exterior dimension(mm) | 3549(W)*5915(L)*2300(H) | 3549(W)*5915(L)*2300(H) |
| Interior dimension(mm) | 3349(W)*5715(L)*2100(H) | 3349(W)*5715(L)*2100(H) |
| Refrigeration unit(model/power) | DC-80FLG/7500W | DC-30FHG/2650W |
| Cooler(model/power) | DD60/1100W | DL30/270W |
| Refrigeration unit (packing size/weight) | 940mm(W)*340mm(L)*1240mm(H) /110kg | 920mm(W)*320mm(H)*850mm/53kg |
| Cooler(packing size/weight) | 1330mm(W)*605mm(L)*630mm(H)/65kg | 1580mm(W)*425mm(L)*465mm(H)/49kg |
| Storage temperature | -18 | -5 |
Cooling room and freezing room
| Model | DCEWF-43 | DCWR-43 |
| Refrigeration storage volume(m3) | 43 | 30 |
| Exterior dimension(mm) | 4732W*4732L*2300H | 4732W*4732L*2300H |
| Interior dimension(mm) | 4532W*4532L*2100H | 4532W*4532L*2100H |
| Refrigeration unit(model/power) | DC-80FLG/7500W | DC-40FHG/3800W |
| Cooler(model/power) | DD60/1100W | DL30/270W |
| Refrigeration unit (packing size/weight) | 940mm(W)*340mm(L)*1240mm(H) /110kg | 920mm(W)*320mm(H)*850mm/53kg |
| Cooler(packing size/weight) | 1330mm(W)*605mm(L)*630mm(H)/65kg | 1580mm(W)*425mm(L)*465mm(H)/49kg |
| Storage temperature | -18 | -5 |
walk in freezer and cooler
| Model | DCEWF-54 | DCWR-54 |
| Refrigeration storage volume(m3) | 54 | 54 |
| Exterior dimension(mm) | 4732W*5919L*2300H | 4732W*5915L*2300H |
| Interior dimension(mm) | 4532W*5715L*2100H | 4532W*5715L*2100H |
| Refrigeration unit(model/power) | DC-80FLG/7500W | DC-50FHG/4850W |
| Cooler(model/power) | DD60/1100W | DL40/500W |
| Refrigeration unit (packing size/weight) | 940mm(W)*340mm(L)*1240mm(H) /110kg | 940mm(W)*340mm(H)*1240mm/110kg |
| Cooler(packing size/weight) | 1330mm(W)*605mm(L)*630mm(H)/65kg | 1330mm(W)*605mm(L)*630mm(H)/68kg |
| Storage temperature | -18 | -5 |
Remark:
(1)cold room panel: polyurethane insulated panel,cam lock type ,density about 43kg/m3,with flame retardant
(2)cold room door: convex door (can be changed to hinge door)
(3)refrigeration unit: Copeland brand,Bitzer brand,with CE certificate
(4)all necessary fittings included.
