cold room hinged door with stucco embossed aluminum material
cold room hinged door features
1. Inside of the Cold room hinged door is made with Bayer polyurethane material by high pressure foaming.The density is up to 43kg/m3 or above.
2. The thickness of panel is 50/75/100/150mm for choice.
3. The Cold room hinged door is made by heavy duty door hinge,heavy duty door lock and hydraulic door closer.
cold room hinged door specification
Door thickness |
50,75,100,150mm |
|||
Standard hinged door |
830x1900H |
|||
(Width) |
(High) |
(Width) |
(High) |
|
Single side door |
900 |
1800 |
1000 |
1812 |
1200 |
2000 |
1300 |
2012 |
|
1500 |
2200 |
1600 |
2212 |
|
1800 |
2400 |
1900 |
2412 |
|
2100 |
2600 |
2200 |
2612 |
|
2400 |
2800 |
2500 |
2812 |
|
2600 |
3000 |
2700 |
3012 |
|
Double side door |
(Width) |
(High) |
(Width) |
(High) |
1800 |
2500 |
942 |
2512 |
|
2400 |
2800 |
1242 |
2812 |
|
3000 |
3000 |
1542 |
3012 |
|
cold room hinged door introduction
1. cold room hinged door
1)100% polyurethane insulated under high pressure,high density of 43kg/m,with fire resistance.
2)Heavy duty door hinges
3)Hydraulic door closer,auto-closing
4)Standard size: 832mm W*1860mm H ( Size can be changed according client's requirement)
5)Door thickness optional: 75mm,100mm,150mm
6)Heater(For defrost) voltage: 24V/36V
7)Rubber around to avoid leakness
8)Safety handle mounted on the back of the door panel for inside emergency opening.
2. cold room hinged door
1)100% polyurethane insulated under high pressure,high density of 43kg/m3,with fire resistance.
2)Taiwan hinges
3)Standard size: 800mm W*1900mm H ( Size can be changed according client's requirement)
4)Door thickness optional: 75mm,100mm,150mm
5)Heater(For defrost) voltage: 24V/36V
6)Rubber around to avoid leakness
7)Safety handle mounted on the back of the door panel for inside emergency opening.
3.cold room sliding door
1)100% polyurethane insulated under high pressure,high density of 43kg/m3,with flame retardant.
2)Standard size: 832mm W*1860mm H ( Size can be changed according client's requirement)
| Name | Width(mm) | Height(mm) |
| Sliding door | 900 | 1800 |
| Sliding door | 1200 | 2000 |
| Sliding door | 1500 | 2200 |
| Sliding door | 1800 | 2400 |
| Sliding door | 2600 | 2800 |
| Sliding door | 1800 | 2500 |
| Sliding door | 3000 | 3000 |
3)Door thickness optional: 75mm,100mm,150mm
4)Heater(For defrost) voltage: 24V/36V
5)Rubber around to avoid leakness
6)Safety handle mounted on the back of the door panel for inside emergency opening.
cold room hinged door package
1. Cold room hinged door is usually packed in bubble paper,convenient,use the possible space of the container,save cost.
2.If sent by LCL,they are firstly wrapped in bubble paper, then put into wooden/plywood case,stronger packing to protect the panels away from damage caused by transportation.
