Blast Freezer for Vegetables Freezing at -45 Degree C

Blast Freezer for Vegetables Freezing at -45 Degree C thumbnail-1
Blast Freezer for Vegetables Freezing at -45 Degree C thumbnail-2
Blast Freezer for Vegetables Freezing at -45 Degree C thumbnail-3
Blast Freezer for Vegetables Freezing at -45 Degree C thumbnail-4
Blast Freezer for Vegetables Freezing at -45 Degree C thumbnail-5
Blast Freezer for Vegetables Freezing at -45 Degree C thumbnail-6
Blast Freezer for Vegetables Freezing at -45 Degree C photo-1
Blast Freezer for Vegetables Freezing at -45 Degree C photo-2
Blast Freezer for Vegetables Freezing at -45 Degree C photo-3
Blast Freezer for Vegetables Freezing at -45 Degree C photo-4
Blast Freezer for Vegetables Freezing at -45 Degree C photo-5
Blast Freezer for Vegetables Freezing at -45 Degree C photo-6
US$ 5,300 - 13,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
DC
Model Number:
BF-2SS
Contact Supplier Request Quote Chat Now
Dongguan City Dachang Refrigeration Electrical & Mechanical Engineering Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
foshan china
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name DC
Model Number BF-2SS
Type Other, Blast freezer
Style Single-temperature
Certification CE
Capacity 250~300 KG Food
Temperature -45 degree C
Refrigerant R404a

Blast freezer   for vegetables freezing at -45 degree C



Blast freezer    PERFORMANCE:


Blast freezer   can lower the food temperature from 28°C to -35°C or -45 degree C within 2~3 hours. Chilling and freezing times will vary somewhat, depending on the food quantity, initial temperature, density, moisture content, specific heat, and type of container. The airflow has a high velocity, indirect pattern designed to cool all levels at identical rates. Time/temperature chilling and freezing rates meet or exceed all FDA and state regulations.





Product Description



  •  Blast freezer   Product Feature

1. All in stainless steel 304 in both sides , exterior 1.0 mm thick , interior 0.8 mm thick

 2. Imported compressor , famous brand Bitzer /Copeland /Tecumseh(air cooled)

3.   Blast freezer   can freezer the food from 60kg ~400kg

 4. we can design the module  Blast freezer    or the finished assembled   Blast freezer     room

5. Environment-protection Refrigerant :R404a

 6.hight quality with CE Rosh

7.OEM Order is welcome !



 Following is the information of the   Blast freezer   for 250~300kg vegetables  freezing



The freezing temperature can reach -45  degree centigrade

 Blast freezer for vegetables freezing at -45 degree C

  Model Number BF-2 BF-2-S
    condensing unit  built-in (on the top)  split unit ( install outside)
1. Unit Dimensions (MM):   1630*1200*2140   L1860*W1690*H2140 mm
2. Inner Dimensions (MM):   1300*960*1420   L1860*W1690*H2140mm
3. Packaging Dimensions (MM):   1690*1260*2240   l1920*W 1750*H 2240mm
4. Capacity can hold 100~150kg     vegetables  Can hold 250~300kg  strawberry
5. freezing Time It can brin vegetables from +25 °C to -45°C  in 2~3hrs   It can bring  vegetables   from +25 °C to -45°C  in 2~3hrs
6. with single  trolley double trolleys of 18 tiers double trolleys of 28 tiers
7. trolley size (MM): 500X600X1400   500X600X1850
8. compressor Bitzer    Bitzer
9. Refrigerant: R404a  R404a
10. material PU material&stainless steel SS304   PU material&stainless steel SS304
12. Voltage 380V/50HZ  380V/50HZ
13. G.W./N.W. 400kg/320kg  400kg/320kg

 Blast freezer for vegetables freezing at -45 degree C



  •  Blast freezer  CONSTRUCTION:



The chilling/freezing cabinet is constructed of polished type 304 stainless steel, with 2" of CFC-free, high density polyurethane insulation 120mm. The door is equipped with a removable magnetic gasket. The door is hinged on operator’s right.





In order to know more about our   Blast freezer   , please check the follwing detailed pictures



All in stainless steel 304 in both sides , exterior 1.0 mm thick , interior 0.8 mm thick

 Blast freezer for vegetables freezing at -45 degree C

  •  Blast freezer   Refrigeration Unit :



The self-contained refrigeration system includes a condensing unit using R-404A refrigerant. The compressor is a Bizter   twin-stage semi- hermetic air cold condensing unit  , with inherent overload protection.

 Blast freezer for vegetables freezing at -45 degree C

 Blast freezer for vegetables freezing at -45 degree C



Blast freezer    Refrigeration Unit can be installed at the top on the

  Blast freezer    (built-in type refrigeration uint)



Blast freezer for vegetables freezing at -45 degree C

or installed separate from the  Blast freezer     ( split refrigeration unit , stand free )

  Blast freezer for vegetables freezing at -45 degree C

  • Each   Blast freezer    will with Trolley. Trollery size is 500X600X1400 mm ( 18 layers) or 500*600*1850 ( 28 layers)





Blast freezer for vegetables freezing at -45 degree C

Blast freezer for vegetables freezing at -45 degree C

  • The  Blast freezer    is with the slope ,which conventient for the trolleys put into the  Blast freezer



Blast freezer for vegetables freezing at -45 degree C



  Blast freezer    temperature can fall down to -45 degree C (just accprding to the food feature  and size) , it can be Auto-defrosting   ( no frost design )

Blast freezer for vegetables freezing at -45 degree C

 Blast freezer    is No frost inside even if in the very low temperature , because it is with auto defrost system design

Blast freezer for vegetables freezing at -45 degree C



  •  Blast freezer     door . We can design the door can be auto close ( with magnetism ) . Also , we design the door inner with safty lock .It can open the door inside the   Blast freezer



 Blast freezer for vegetables freezing at -45 degree C





Packaging & Shipping



  • Packaging information for the     Blast freezer

1. for   Blast freezer   sample , we will package it by  plywood case

2. for full conatainer loading, we will package  Blast freezer     by batten

Blast freezer for vegetables freezing at -45 degree C

  • Blast freezer   Application :



Blast freezer    mainly apply to the restaurant ,cafe, icecream store ,ect .It can freezer/chill the food to the low temperature in short time .

we can also do the  Prefabricated   Blast freezer     room for the large capacity usage . It can freezer 1000kg ~5 tons food .



Blast freezer for vegetables freezing at -45 degree C






FAQ



we are the manufacturer to do the Blast freezer   , So OEM order is welcome . In order to design the suitable Blast freezer   for your , please answer us the following quesions:
1. What kind of food will be put into the Blast freezer    ?
2. what;s the food size (such as length ,width ,thick ) ?
3.what kind of the food package and the food packaging size ?
Plastic bag or stainless steel tray
4.what;s the foods weight for each bag or each tray?
5.how many food will be put into the Blast freezer   per batch ?
6.what;s the food input temperature and the output temperature ?
7.what's the food core temperature after frozen ?
8.what's the freezing time ?
9.what;s the voltage for the Blast freezer    you required ?
