Shock Freezer for BAKERY
Shock Freezer Product Feature
1. All in stainless steel 304 in both sides , exterior 1.0 mm thick , interior 0.8 mm thick
2. Imported compressor , famous brand Bitzer /Copeland /Tecumseh(air cooled)
3. Shock Freezer can freezer the food from 60kg ~400kg
4. we can design the module Shock Freezer or the finished assembled Shock Freezer
5. Environment-protection Refrigerant :R404a
6.hight quality with CE Rosh
7.OEM Order is welcome !
Shock Freezer PERFORMANCE:
Shock Freezer (soft or hard) lowers the food core temperature from 70°C to +3°C in less than 2 hours. Shock freezing Blast Chiller lowers the food core temperature from 70°C to -25°C within 3~4 hours. Chilling and freezing times will vary somewhat, depending on the food quantity, initial temperature, density, moisture content, specific heat, and type of container. The airflow has a high velocity, indirect pattern designed to cool all levels at identical rates. Time/temperature chilling and freezing rates meet or exceed all FDA and state regulations.
Shock Freezer specification
| Model Number | BF001 | BF001-S | |
| condensing unit | built-in | split unit | |
| 1. | Unit Dimensions (MM): | 1200*1080*2140mm | 1200*1080*2140mm |
| 2. | Inner Dimensions (MM): | 960*740*1420mm | 960*740*1420mm |
| 3. | Packaging Dimensions (MM): | 1260*1160*2240mm | 1260*1160*2240mm |
| 4. | Capacity | can hold 60kg food | Can hold 100kg food |
| 5. | freezing Time | It can bring A food from +70 °C to +3°C (product core temp.) in 2~3hrs | It can bring A food from +70 °C to +3°C (product core temp.) in 2~3hrs |
| 6. | with single trolley | Single trolley of 18 tiers | Single trolley of 28 tiers |
| 7. | trolley size (MM): | 500X600X1400 | 500X600X1400 |
| 8. | compressor | Bitzer /Copeland /Tecumseh(air cooled) | Bitzer /Copeland /Tecumseh(air cooled) |
| 9. | Refrigerant: | R404a | R404a |
| 10. | material | PU material&stainless steel SS304 | PU material&stainless steel SS304 |
| 11. | Power | 3kw | 3kw |
| 12. | Voltage | 380V/50HZ | 380V/50HZ |
| 13. | G.W./N.W. | 280KG /360KG |
we are the manufacturer to do the Shock Freezer , So OEM order is welcome . In order to design the suitable Shock Freezer for your , please answer us the following quesions:
1. What kind of food will be put into the Shock Freezer ?
2. what;s the food size (such as length ,width ,thick ) ?
3.what kind of the food package and the food packaging size ?
4.what;s the foods weight ?
5.how many food will be put into the Shock Freezer per batch ?
6.what;s the food input temperature and the output temperature ?
7.what's the food core temperature after frozen ?
8.how long to reach the output temperature ?
9.what;s the voltage for the Shock Freezer you required ?
you can fill in this form and feed back to us . Then we will send you the Shock Freezer design for your reference :
| Product |
| product(meat or others) length (mm) |
| product(meat or others.) width (mm) |
| product(meat or others) Thick(mm) |
| product(meat or others) weight(kg) |
| product(meat or others) packing |
| Capacity/batch |
| Input temperature(°C) |
| Output temperature(°C) |
| Time to reach the output temperature |
| Product core temperature after freezing(°C) |
| Trolley |
| Votage & Frequency |
| Need any certificates?(CE,ETL,ROHS etc) |
Shock Freezer CONSTRUCTION:
The chilling/freezing cabinet is constructed of polished type 304 stainless steel, with 2" of CFC-free, high density polyurethane insulation 120mm. The door is equipped with a removable magnetic gasket. The door is hinged on operator’s right.
In order to know more about our Shock Freezer , please check the follwing detailed pictures
All in stainless steel 304 in both sides , exterior 1.0 mm thick , interior 0.8 mm thick
Shock Freezer Refrigeration Unit :
The self-contained refrigeration system includes a condensing unit using R-404A refrigerant. The compressor is a semi- hermetic type with inherent overload protection.
The Shock Freezer Refrigeration Unit can be installed at the top on the
Shock Freezer (built-in type refrigeration uint)
or installed separate from the Shock Freezer ( split refrigeration unit , stand free )
Each Shock Freezer will with Trolley. Trollery size is 500X600X1400 mm
The Shock Freezer is with the slope ,which conventient for the trolleys put into the
Shock Freezer
Shock Freezer temperature can fall down to -35 degree C (just accprding to the food feature and size) , it can be Auto-defrosting
Shock Freezer door . We can design the door can be auto close . Also , we design the door inner with safty lock .It can open the door from the Shock Freezer
Packaging information for the Shock Freezer
Shock Freezer Application :
Shock Freezer mainly apply to the restaurant ,cafe, icecream store ,ect .It can freezer/chill the food to the low temperature in short time .
we can also do the Prefabricated Shock Freezer room for the large capacity usage . It can freezer 1000kg ~5 tons food .
