Auqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mm

Auqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mm photo-1
Auqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mm photo-2
Auqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mm photo-3
Auqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mm photo-4
US$ 1 - 100 MOQ: 100 Meters
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Auqi
Model Number:
MI cable
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name Auqi
Model Number MI cable
Usage Industrial
Theory Temperature Sensor

MI Cable

Product Description



Other name:  MI cable
Diameter:  3mm
Inner Material:  Nickel Or Copper Conductors
Outer material:  304,321,310,316,INconel600,GH3030
Insulator:  Magnesium oxide
thermocouple:  Single or double
Types of sensor:  K
Sensor end:  Insulation or shell-connection
Certification:  ISO9001, ISO14001



Auqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mmAuqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mmAuqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mm

Auqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mm

 Auqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mm

1 Thermocouple graduation

B

B type   600---1700°C

R

R type   0---1600°C

S

S type   0---1600°C

N

N type   0---1100°C

K

K type   0---1000°C

E

E type   0---800°C

J

J type   0---750°C

T

T type   -40---350°C

P

P t type   -200---600°C

C

Cu type   -200---100°C





7 Outer protection sleeve material code

A

1Cr18Ni9Ti (or SS321)

B

0Cr18Ni9 (or SS304)

C

0 Cr18Ni12Mo2Ti (or SS316)

D

0Cr25Ni20 (or SS310)

G

Nickel-based heat resistant and anti-corrosion alloy (or Inconel600)

HB

Hastelloy Alloy B-2

HC

Hastelloy Alloy C-276

MK

Monel K-500

TP91

ASTM A335P91

TP92

ASTM A335P92

TP11

A691Cr1-1/4CL22

TP22

A691Cr2-1/4CL22

W

Wb36 (or 15NiGuMoNb5)

E

00Cr22Ni5Mo3N (double-phase stainless steel 2205)

F

PTFE

Others

Others (or ordered material)

8 Mineral Insulated thermocouple (RTD) diameter

05

Φ0.5

10

Φ1

20

Φ2

30

Φ3

40

Φ4

50

Φ5

60

Φ6

80

Φ8

95

Φ9.5

127

Φ12.7

9 Total length

L

(mm)

10 Accuracy class

Accuracy classⅠ(0.4%t)

Accuracy classⅡ(0.75%t)

Please note in the brackets for special accuracy requirements

Example:Ⅲ(0.3%t)indicate:tolerance range 0.3%t

11Insertion depth(if any)

U

(mm)


Company Information



Ningbo Auqi Auto-Instrument Equipment Co., Ltd was established in 1996 which is  one of the earliest manufactures of sheathed thermocouple, the largest sheathed materials producers in China and  the largest temperature elements exporting enterprises in China,  With a 50% domestic market share.  specializing in thermocouple,RTD,Electrical Heat Equipment ,thermoresistor,MgO Cable for thermocouple,other sheathed thermocouple materials   etc,mainly exporting to North America, Europe, Canada, Japan, Korea and etc.After 16 years’ hard work and innovation, ”Auqi” has become a leading company in the felid of producing instruments in China and successively become a standing director unit of Instruments Material Branch of China Instruments Manufacturers Association, a director unit of China Temperature Instruments Association and China Nuclear Industry Association.


 Auqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mm

Auqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mm

Auqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mm



 Auqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mmAuqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mmAuqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mm    Auqi High Density Armoured Magnesium Oxide Minerally Insulated Thermocouple Cable Diameter 1mm



Send Inquiry to This Supplier

Message
0/5000

Want the best price? Post an RFQ now!
Business Type
Manufacturer
Year Established
1996
Factory Size
10,000-30,000 square meters
Total Employees
101 - 200 People
