Supply Steel Strapping for Package

Name: Supply Steel Strapping for Package
Brand: Qin Huangdao TongYe cold rolled steel strip
SKU: 125550751
Availability: InStock

US$ 500 - 720 MOQ: 20 Metric Tons

Key Specifications

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Steel Grade:

Other, DB460

Thickness:

0.4-1.2

Qinhuangdao Tongye Cold-Rolled Strip Steel Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

DALIAN CHINA

Delivery Detail:

Delivery time depends on order quantity.

Standard AISI, ASTM, BS, DIN, GB, JIS

Steel Grade Other, DB460

Thickness 0.4-1.2

Place of Origin Hebei, China

Technique Cold Rolled

Surface Treatment Polished

Application Round saw ,band saw, cotton machine, friction disk, hose bands, hard-w

Model Number no required

Brand Name Qin Huangdao TongYe cold rolled steel strip

Width 19mm,25mm,32mm

Length no required

oscilatted steel strapping

strap size			Intermediate tensile strength		High tensile strength		Ultra-high tensile strength		Yield		Coil weight
width		Thickness (mm)	Average Strength		Average Strength		Average Strength		ft/lb)	(M/kg)	Ribbon Coil
(mm)	(inch)	Thickness (mm)	≥ 735Mpa/ ≥5%	≥ 785Mpa/ ≥6%	≥ 880Mpa/ ≥8%	≥ 930Mpa/ ≥8%	≥ 980Mpa/ ≥12%	≥ 1250Mpa/ ≥6%	ft/lb)	(M/kg)	kg)	(ib)
19.00	3/4	0.5	6983N	7458N	8360N	8835N	9310N	11875N	20.0	13.41	90	198
		0.6	8379N	8949N	10032N	10602N	11172N	14250N	16.6	11.17	90	198
		0.7	9776N	10441N	11704N	12369N	13034N	16625N	14.3	9.58	90	198
		0.8	11172N	11932N	13376N	14136N	14896N	19000N	12.5	8.38	90	198
		0.9	12569N	13424N	15048N	15903N	16758N	21375N	11.1	7.45	190	418
		1.0	13965N	14915N	16720N	17670N	18620N	23750N	10.0	6.7	190	418
25.00	1	0.6	11025N	11775N	13200N	13950N	14700N	18750N	12.6	8.49	400	880
		0.7	12863N	13738N	15400N	16275N	17150N	21875N	10.8	7.28	400	880
		0.8	14700N	15700N	17600N	18600N	19600N	25000N	9.5	6.37	400	880
		0.9	16538N	17663N	19800N	20925N	22020N	28125N	8.4	5.66	400	880
		1.0	18375N	19625N	22000N	23250N	24500N	31250N	7.6	5.1	400	880
31.75	1-1/4	0.8	18669N	19939N	22352N	23622N	24892N	31750N	7.5	5.02	500	1100
		0.9	21003N	22431N	25146N	26575N	28004N	35719N	6.6	4.46	500	1100
		1.0	23336N	24924N	27940N	29528N	31115N	39688N	6.0	4.01	500	1100
		1.12	26137N	27915N	31293N	33071N	34849N	44450N	5.3	3.58	500	1100
		1.2	28004N	29909N	33528N	35433N	37338N	47625N	5.0	3.33	500	1100
