1:Product description
Thank you very much for purchasing our company solar DVR camera, for a better use the product and know it's performance , please read the instruction carefully before use.
2:Applied range: yard light/ home security, outdoor/indoor use etc
This model: ZJ39TLR Smart Solar DVR Light, working 24 hours a day, Energy saving and friendly with environment.
Power supply: by sun / home electricity, both is OK.
LED on : while some one moving at night
LED off : daytime / nighttime no one moving
Video record : 24 hours stand by, activated by some one moving
3:Features:
- Hight color CMOS chip
- Support 32GB TF card
- USB1.0port
- Support PC-CAM function
- Support U disk function
- Support solar charge and home electricity charge
- Built- in high capacity battery
- PIR motion detect and video record AUTO
- Support over write function
- Video support date stamp
- 39pcs super white LED light for lighting
- Support Windows ME/Windows2000/Windows XP/Windows Vista operate system
Parameter:
Solar or not : yes
White LED: 10-25LUX
White LED quantity: 39pcs
White LED shining distance: 4-7meters
Image format: JPEG(video or take photo functions,default set video function)
Image video resolution:: 1280*960
video: AVI
Video resolution: 640*480 25-30 fps/S
Video record time:10s/clip
Over write video record:delete first video write in new video base on TF card full.
PIR detect distance: 4-6meters
TF card: 64M--32GB
Solar voltage:5V/0.2A
External source : DC:5V/1A
Li-battery:2000mah
Hours of operating:Charge full, without solar power and external source,white lights off and camera work can continue operating 7-8hours, LED lights on about 4-6 hours.
Charge Current:160-200ma
Re-charge time:12-14 Hours
Work current: 560MA MAX(do not include charge current)
size:
weight:1.1 kg
Working temperature:-20-50 degree
Storage temperature: -40-85 degree
7:accessories
A: USB line B:Drive CD C: DC 5V/1A power adapter
8:problems and solve solution
1:I Had insert TF card and PIR have induction,red light on as well as blue light,but it couldn't video record.(blue light don't shining)
Answer:Check the TF card inserted well, blue light on not shining it do not take video. Extract TF card out and connect to the pc, if it's OK, format it and insert it in the solar product detect again.
2:images unclear
Please confirm the camera no dirt
3:Solar couldn't charging
Please assure that sunshine can shine on the solar panel.
4:software can not installation successful
When you installing the software, please shut down antivirus software firstly, sometimes the antivirus software will kill the EXE file as virus.
