Wireless mini digital camera for baby

Features Of Wireless mini baby monitor

Function Introduction
*Adopt 2.4GHz Frenquency transmission,accord with FCC,CE Standard;
*With high resolution 2.4” LCD display screen;
*Have operation text menu display function;
*Support one receiver can connect 4 transmitters;
*Long-distance transmission:Up to 200-300m in open air;
*Day and night monitoring with clear images for 24 hours;
*Half-duplex Voice Transmission,Voice clear, volume of sound (0~10) is adjustable;
*Adjustable LCD screen,the brightness of LCD (0-10) is adjustable
*Vox Alarm function,the volume of baby sound or happened in baby room over the volume which software of baby monitor has been fixed will alarm to monitor (screen automatically turn off,and then turn on with sound), to remind parents to pay more attention to baby.
*Monitor with TV Out function,support TV display;
*Monitor with real time function,and display real time information;
*Inspecting baby room’s temperature,and showing real temperature on LCD monitor.
*Support music player,eg, play sleeping music to help baby go to sleep.
*With pairing code function: make pairing through the pairing code buttons of monitor and camera

a:Function
Function Description
Frame Rate 15-25 Frame,Signal strong,frame high
Signal strength indication 6 grade
Voice Volume 10 grade
Talkback Two-way talk, half-duplex
VOX Switch on automatically when there is voice
One monitor with 4 transmitter One receiver with 4 cameras,switch CH display

Temp Alarm Yes
Realtime clock Yes,24 hours system
Temperature display Yes
Music Player Yes
LCD Size 2.4inch 320*240 RGB color LCD
Transmission safety Use after pair code

b:  Electrical parameters
Work Voltage  DC:+5V/500MA;Battery:4*AAA=1.5*4
Frequency  2.4GHz ISM Band
Wireless Work Method  FHSS
Transmission Power  19dBm@CW mode
Transmission rate  3Mbps
Operating Range  Open field:200-300 meter
Work current(Transmitter and receiver)  TX:300mA  MAX,RX:300mA  MAX
Work current for Auto sleep TX:35mA(once every 0.5s)RX:20mA(once every 0.5s)
Audio rate  16K
Audio range  120Hz~3KHz
Sleep music funtion 12 musics looping
Temp Alarm  --10°C or-36°C
VOX Power  -60dB@ MIC Input
Camera resolution  0.3 Mega
Picture resolution  320*240QVGA
AV OUT function  5-15 frame VGA from AV Output
Video Rate  15-25FPS
Total harmonic distortion  <5.0%
SNR  46dB
Receiving Sensitivity  -96dBm@BER=1e-3
Speaker  0.25W
Night vision range  2—3 meters
Operating Humidity 20~95%
Operating Temperature  0°C~38°C

Packing


 Gift Box Size:32x18x7.5cm
 Carton Box Size:39x33x37cm
 1 gift box:1 Unit
 1 Carton Box:10 sets
 Gross Weight:10kg/carton
 Net weight:9kg/Carton
 weight:0.9kg/Carton
