New Technology Automatic Copper Wire Drawing Machine
Below information is needed for quick quotation
1.Wire diameter coming: mm(adjustable)
2.Wire diameter outing: mm(adjustable)
3.Industrial voltage : 380V 50HZ ( customized)
4.Your other requirements: .
Advantage of wire drawing machine
- Simple structure,low cost,easy operate,broad scope of application
- More than one motor for the wire drawing,multi-drawing,high the working efficiency
- Full automatic operation,need less professional knowledge
- Scope of application:gas security wire,welding electrode wire,stainless steel wire,galvanized iron wire,medium and high-carbon steel wire,copper wire,wire and other metal products used ect
Technical parameter of wire drawing machine
| spec | drawing path times | max wire comming(mm) | mini wire outing(mm) | motor power(kw) | max speed(m/s) | runing form |
| 650 | 1-4 | 8.0 | 4.0 | 22-15 | 2 | gear running |
| 560 | 1-7 | 6.5 | 2.0 | 22-11 | 6 | gear running |
| 450 | 1-7 | 3.5 | 1.2 | 18.5-15 | 7 | gear running |
| 400 | 6-8 | 2.5 | 0.8 | 11-15 | 18 | triangle belt runing |
| 360 | 1-7 | 2.5 | 0.6 | 11-7.5 | 8 | gear running |
Maintenance for wire drawing machine
- Keep the distance for other machine
- And check the data,and confirm out mistake
- The power cord should be protective,to ensure safety production
- The wire without rust
- Clean the machine at regular int
Brief introduction of company
Hengtai Wire Mesh Machinery factory has been specificialized in producing all kinds of welded wire mesh machine for 15 years and whicn bring us a lot of customers abroad and experience intrade.All wire mesh machines of us are in accordance with national standard
Reason for choosing us
- Rich Domain Experience
- Professional Engineers
- More than 120 Workers
- With the occupying area of 6800 square meters
- Wide Business Network
- Competitive price and high quality
- Good After-sale Service
- Near Tianjin Port
Our services
Good after-sale service
Guarantee time: one year since the machine was installed at buyer's factory
We can send our best engineer to buyer’s factory for installation, debugging and training
As per your special requirement, we can discuss it
Payment Terms
1. 30% T/T in advance, 70% payable against the copy of the B/L
2. L/C is also acceptable
3. As per your special requirement, we can discuss it
A.We are a factory and have do business more than 15 years
A.In wooden pallet,In plastic film,the spare parts and cabinet packed by wooden box
A.Usually by T/T ( 30% in advance, the balance against the copy of B/L)
A.We have an inspection team to check the products at all stages of the manufacturing process
Q:What parameter is necessary?
A.The wire diameter,mesh size,mesh width ect are mainly needed, detailed information would be appreciated, Special requirement can be discussed
Welcome to visit our company
Any information from you would be appreciated
