Advanced Technology CNC Sheet Metal Punching Machine
Below information is needed for quick quotation
1. Punching thickness: mm(adjustable)
2. Mesh Size: mm2(adjustable)
3. Mesh width: mm ( customized)
4. Industrial voltage : 380V 50HZ ( customized)
5. Do you want to weld wire mesh panel or mesh in coil?
6.Your other requirements: .
Specification of sheet metal punching machine
- Can also be punching stainless steel plate mesh,aluminum and other materials
- Use some such as automatic lubrication,new technologies,such as CNC stepper motor feed
- The machine structure rationality,beautiful,environmental protection,energy saving
-
Punching width and thickness are adjustable
Usage
Mainly used in mechanical,electrical,electronics,hardware and protective domain
Technical parameter of sheet metal punching machine
Type |
JQ25-6.3A |
JQ25-16 |
JQ25-25 |
JQ25-63A |
JQ25-63B |
JQ25-100 |
Depth(mm) |
max.1.0 |
max.1.0 |
max.1.5 |
max.2.5 |
max.3 |
max.4 |
Width(mm) |
500 |
1000 |
1250 |
2000 |
2000 |
2000 |
Times |
180/min |
150/min |
150/min |
70/min |
45/min |
60/min |
Distance(mm) |
0-1.15 |
0-1.2 |
0-1.2 |
0-4 |
0-4 |
0-4 |
Length(mm) |
max.20 |
max.25 |
max.30 |
max.100 |
max.200 |
max.150 |
Motor |
2.2KW |
3KW |
4KW |
11KW |
11KW |
15KW |
Weight |
0.95T |
2T |
3T |
10T |
10T |
12T |
Dimension(mm) |
950*570 *1780 |
1800*1320 *1550 |
1940*1600 *2010 |
2400*3500 *2300 |
2400*3500 *2300 |
3600*2500 *3000 |
Maintenance for sheet metal punching machine
- Keep the distance for other machine
- And check the data,and confirm out mistake
- The power cord should be protective,to ensure safety production
- The wire without rust
- Clean the machine at regular int
Brief introduction
Hengtai Wire Mesh Machinery factory has been specifucualized in producing all kinds of welded wire mesh machine for 15 years and which bring us a lot customers abroad and experiences in trade
- Was found in 1999,more than 120 Workers
- Covers an area of 5800 square meters
- Wide Business Network
- Good After-sale Service and near Tianjin Port
- All wire mesh machines of us are in accordance with national standard
Our services
- Guarantee time: one year since the machine was installed at buyer's factory
- We can send our best engineer to buyer’s factory for installation, debugging and training
- Do our best to help customer arrange the shipment.
- As per your special requirement, we can discuss it
Payment Terms
- Payment Terms:30% T/T in advance,70% payable against the copy of the B/L;L/C Western union are also acceptable
- Lead Time:15-20 days according to the final amount on order
- MOQ:one set
- Port:Tianjin
- Shipment: By sea
- Packaging:The machine is with plastic bag to the container or as customers' requirement
A.We are a factory and have do business more than 15 years
A.In wooden pallet,In plastic film, the spare parts and cabinet packed by wooden box
A.Usually by T/T ( 30% in advance, the balance against the copy of B/L)
A.We have an inspection team to check the products at all stages of the manufacturing process
A.If need engineer oversea service,the customer need to pay the round air tickets,hotel,food and wage
Any questions contact me freely, I will try my best to help you
