1.CS-B single twisted Barbed Wire Machine
CS-B single twisted Barbed Wire Machine is designed to produce screens with single or double-stranded barbed steel wire,thermo-plated with zinc.The machine is of horizontal design,consisting of two parts,assembled together at the middle.It is safe and reliable in operation,capable of turning out high quality products with consistency.
Item |
|
Motor |
2.2kw |
Rated output |
50kg/h |
Weight |
1200kg |
Overall Dimension |
1900mmx1300mmx980mm |
Wire collection part size |
1300mmx800mmx700mm |
Barb pitch spacing |
As required |
Twist |
4,6 |
Strand Diameter |
1.6-2.6mm |
Wire Diameter |
1.6-2.2mm |
Rotating Speed of Drive shaft |
357r/min |
2. CS-A Double twisted Barbed Wire Machine
CS-A double twisted barbed wire machine is designed to produce screens with single or double-strand barbed steel wire,thermo-plated with zinc.The machine is of horizontal design,consisting of two parts,assembled together at the middle.It is safe and reliable in operation,capable of turning out high quality products with consistency.
Item |
|
Motor |
3kw |
Rated output |
70kg/h |
Weight |
1500kg |
Overall Dimension |
1900mmx1300mmx980mm |
Wire collection part size |
1800mmx750mmx750mm |
Barb pitch spacing |
76mm 102mm |
Twist |
4 |
Strand Diameter |
2.2-2.8mm |
Wire Diameter |
1.8-2.2mm |
Rotating Speed of Drive shaft |
432r/min |
Company
Hengtai Wire Mesh Machinery factory has been specificialized in producing all kinds of welded wire mesh machine for 16 years and which bring us a lot of customers abroad and experiences in trade.
Advantage of our company
1. Rich Domain Experience.
2. Professional Engineers.
3. More than 120 Workers.
4. With the occupying area of 5800 square meters.
5. Wide Business Network.
6. High Quality and Good After-sale Service.
7. Near Tianjin Port
The Warranty
1.Reply you enquiry in 24 hours working hours
2.Experienced staffs answer all your questions about the machine
3.Exclusive and unique solution can be provided to our customer by your well-trained and professional engineer.
4.Special discount and protection of sale area provided to your distributor.
5.Engineer can install,test and adjust the machine for you when the machine arrived your factory 7days.
6.Engineer can repair machine to your factory
7.Guarantee: one year, some accessories free for you.
Payment Terms
1. 30% T/T in advance, 70% payable against the copy of the B/L.
2. L/C is also acceptable.
3. As per your special requirement, we can discuss it.
Q: Does your company is a factory or trading company?
A.We are a factory and have do business more than 15 years.
Q: What's the producing time and delivery time?
A.If we have stock, delivery to Tianjin port about 5 days, No stock, it wil be 20-30days after received your deposit.
Q: what's the packing of the machine
A.In wooden pallet, In plastic film, the spare parts and cabinet packed by wooden box.
Q: What's the payment term?
A.Usually by T/T ( 30% in advance, the balance against the copy of B/L)
Q: Can I change the motor as my local voltage?
A.We can change the voltage as your requirement, and there's no extra charge.
Q: Can you OEM( use my logo and color)?
A.We can OEM with your logo and color design.
Q: Does machine have guarantee period?
A. One year gurantee for whole machine except vulnerable parts
Q: How do your control quality?
A. We have an inspection team to check the products at all stages of the manufacturing process-raw material,
woven fence process or test finished products, etc. 100% inspection in assembly line to achieve the required
quality levels.
