Item No.: JB-205/35
We are Motor Factory
JIABO JB-205/35 high torque dc brushless hub motor is applied for electric bike
PRODUCT DRAWINGS
PRODUCT PICTURES
PRODUCT SPECIFICATIONS
Rated Voltage(V) |
24/36/48/60 |
Rated Power(W) |
350-1000 |
Wheel Size |
20”-28” |
Rated Speed(km/h) |
25-35 |
Rated Efficiency (%) |
>=85 |
Reduction Ratio |
/ |
Weight (Kg) |
6 |
Open Size(mm) |
135 |
Drive and Freewheel |
6-8s |
Cable Location |
Shaft center right |
Spoke Specification |
10g/12g/13g |
Hall Sensor |
Optional |
Integrate speed sensor |
Optional |
Surface |
Black/Silver |
Brake Type |
V brake/Disc |
Salt fog test(h) |
24/96 |
Noise(db) |
<60db |
Waterproof Grade |
IP65 |
PRODUCT FEATURES
Our JIABO JB-205/35 high torque brushless dc brushless hub motor’s characteristics
l Low noise.
l Electricity saving
l High torque
l High strength
l High safety coefficient, high efficiency
l Long service life
l Not easy to be hot
PRODUCT APPLICATION
JIABO JB-205/35 high torque dc brushless hub motor is applied for electric bike
FACTORY WORKSHOP
QUALITY INSPECTION
COMPANY AND SERVICE
CERTIFICATE
PACKING AND SHIPPING
METHOD OF PAYMENT
FAQ
- QWhat's your motor's Max. rotating speed?
- A600 RPM
- QWhat's your motor's Max power?
- ARated output power is 1000W
- QWhat's your motor's Max torque?
- AWhen the voltage rating is 60V, the Max torque is about 50nm
