wood herb grinder
wood herb grinder Brief introduction:
This machine is mainly used for,wood, twigs , wood powder , bamboo powder , miscellaneous wood powder, cork powder ,bamboo and wood powder, bake lite powder, bamboo, tree bark ,poplar wood powder, pine, redwood,mahogany, cleaning powder,dust cleaning powder, oak powder , Paper-making wood powder, incense wood flour , leather and other the raw material grinding/milling operations.wood powder fineness in 40-325 mesh can be arbitrary control,widely used in chemical , building materials,woodworking, medicine, health protection, breed aquatics ,foodstuff, mosquito-repellent incense ,paper-making, leather and other industries.
wood herb grinder composition:
Cutter ,the knife dish , spindle, the machine body , fineness analyzer ,draught fan, powder collector , dust collector and other components Ministries.
wood herb grinder working principle:
Material from the feed port to feed , grinding tools, high-speed rotation after three knives, the material for compression , friction, tearing and other physical milling mode , complete the material grinding operation ,And then the powder is sent by the qualified fineness fineness analyzer , not qualified powder hopper back through the inlet port to return repeatedly ground until qualified,qualified leads from the fan to the powder , powder collector , dust to dust dust removal operation .
wood herb grinder Features :
1 : The machine adopts the double hollow body, circulating water cooling device can be added internally , pull off the high speed grinding heat problem ;
2: A3 steel knives, broken fire after treatment, more wear-resistant , better crushing effect ;
3: The fineness analyzer , strict control of product fineness , to ensure product quality ;
4 : fineness control devices , according to the fineness required , at any time to adjust the fineness ;
5: the whole machine adopts 6 mm to thicken the chassis, after installation, can be a good damping effect.
wood herb grinder parameter:
Model |
450 |
600 |
750 |
1000 |
|
Max Feed Size (mm) |
3-5 |
3-5 |
3-5 |
3-5 |
|
Material hardness (Morse) |
fiber |
fiber |
fiber |
fiber |
moisture content of materials |
drying |
drying |
drying |
drying |
Grinding fineness (mesh) |
40-325 |
40-325 |
40-325 |
40-325 |
|
Yield (kg/h) |
30-150 |
60-220 |
80-300 |
100-600 |
|
The host power (kw) |
3200 |
3400 |
3200 |
2200 |
|
The host power (kw) |
18.5-22/2 |
22-30/2 |
37-45/2 |
75-90/2 |
|
The fan power (kw) |
5.5/2 |
5.5/2 |
7.5/2 |
15/2 |
Weight (kg) |
1450 |
1850 |
2800 |
5500 |
wood herb grinder Finished Products :
wood herb grinder equipment Exhibition:
