58KN Electric Lifeboat Winch for Gravity Luffing Arm Davit

58KN Electric Lifeboat Winch for Gravity Luffing Arm Davit photo-1
58KN Electric Lifeboat Winch for Gravity Luffing Arm Davit photo-2
58KN Electric Lifeboat Winch for Gravity Luffing Arm Davit photo-3
US$ 8,000 - 15,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
OEM
Model Number:
DS58
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shanghai, China
Brand Name OEM
Model Number DS58
Power Source Electric
Application Boat
Capacity 5~650KN
Product Description

58KN Electric Lifeboat Winch for Gravity Luffing Arm Davit

Certificate: CCS, BV, ABS etc
The boat winch driven by electric motor belongs to a short time working equipment. The boat winch is of two kinds of structures, left-hand and right-hand boat winch which are symmetric. It can be suitable for arranging on the parent ship whose deck are symmetric.

The boat winch is of the functions of hoisting boat by electric, lowering boat by gravity and hoisting boat by manual as well as manual quick lowering device for empty hook. The boat winch is provided with a manual driving unit which can automatically separate, and a interlocking switch. It can avoid the personal injury caused by mis-operation to the maximum.

Equipment Data
Model
DS58(Life Boat)
DZ58( Rescue boat& Life boat)
Max. Working Load
58kn
58kn
Hoisting Load
29kn
29kn
Setting Load
32kn
32kn
Hoisting Speed
≥10m/min
≥ 36m/min
Lunching Speed
80-90m/min
80-90m/min
Dia. of Rope
18mm
18mm
Drum rope Capacity
50m
50m
Detailed Images
More Models
Model Particulars
D50S*
D50Z*
D63S*
D63Z*
D100S*
D100Z*
Length(mm)
1490
1645
1535
1785
1920
2080
Height(mm)
1240
1240
1230
1230
1380
1470
Breath(mm)
855
855
795
795
1210
1210
Weight(kg)
940
1165
990
1300
2980
3800
Base dimension(mm)
580×360
550×305
690×380
690×380
1330×540
1330×540
Max. working load(kn)
50
50
63
63
100
100
Hoisting load(Kn)
28
28
30
30
70
70
Max./Min. lowering load(kn)
31/15
31/15
40/12
40/12
60/25
60/25
Wire rope(mm)
Φ16
Φ16
Φ18~20
Φ18~20
Φ22~24
Φ22~24
Rope capacity(m)
60
60
65
65
2×70
2×70

*    S: Life Boat Winch
      Z: Rescue Boat & lifebat Winch

Application Field
About US

1. We are professional supplier of Electric & Hydrulic life boat and rescue boat davit for more than 10 years.

2. We can guarantee fast delivery time.

3. CCS, EC, BV, ABS certificate can be supplied.
