Metal-oxide Polymer 11KV Surge Arrester / Types of Lightning Arrester /33kv Lightning Arrester
US$ 5 - 55
MOQ: 3 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Qiaotai
Model Number:
YH5W
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Factory Supply 3Phase Outdoor H.V. Zinc Oxide Polymer Surge Lightning ArresterUS$ 3 - 30MOQ: 10 Pieces -
Factory Supply SPD Surge Protective Device CE ApprovalledUS$ 1.5 - 15MOQ: 10 Pieces
-
China Manufacturer Supply Polymer Surge Arrester Lightning for Transmit LineUS$ 5 - 50MOQ: 1 Piece
-
China Supplier Zinc Oxide Surge Lightning Arrester 12KV/24KV/36KV/69KVUS$ 5 - 20MOQ: 3 Pieces
-
More 20Years' ODM Supply Polymer Lightning Protection Arresster With Piercing ConnetcorUS$ 5 - 15MOQ: 3 Pieces
Place of Origin
Zhejiang, China
Brand Name
Qiaotai
Model Number
YH5W
| Metal-Oxide surge arrester | |||||||
| Type | MOA Rated voltage | MCOV | 1/10US Steep Current impluse | 8/20US lightning current impluse | 30/60US switching current impluse | 2us Rectangular current impluse | 4/10us High current impluse |
| kV(r.m.s) | kV | A | kA | ||||
| HY5W-3 | 3 | 2.55 | 11.3 | 9 | 8.9 | 150 | 65 |
| HY5W-6 | 6 | 5.1 | 22.6 | 18 | 16.8 | 150 | 65 |
| HY5W-9 | 9 | 7.65 | 33.7 | 27 | 23.8 | 150 | 65 |
| HY5W-10 | 10 | 8.4 | 36 | 30 | 26.4 | 150 | 65 |
| HY5W-11 | 11 | 9.4 | 40 | 33 | 30 | 150 | 65 |
| HY5W-12 | 12 | 10.2 | 42.2 | 36 | 31.7 | 150 | 65 |
| HY5W-15 | 15 | 12.7 | 51 | 45 | 38.5 | 150 | 65 |
| HY5W-18 | 18 | 15.3 | 61.5 | 54 | 46.2 | 150 | 65 |
| HY5W-21 | 21 | 17.0 | 71.8 | 63 | 54.2 | 150 | 65 |
| HY5W-24 | 24 | 19.5 | 82 | 72 | 62 | 150 | 65 |
| HY5W-27 | 27 | 22.0 | 92 | 81 | 69.8 | 150 | 65 |
| HY5W-30 | 30 | 24.4 | 102 | 90 | 79 | 150 | 65 |
| HY5W-33 | 33 | 27.5 | 112 | 99 | 86.7 | 150 | 65 |
| HY5W-36 | 36 | 29.0 | 123 | 108 | 92.4 | 150 | 65 |
