Specifications
High Frequency generator1)Input Powder: 6-120kw
2)Furniture manufacturing machinery
High frequency generator is using for drying of glue and shaping of wood furniture, shorten production time& increase efficiency
Specially design the HF woodworking machine
Can design the different types and different structure HF generators for you from CGQ-5KW to CGQ-100KW
Double outputs or single output is OK.
Used area is in furniture industry, for drying the wood material with glue.
Technical features:
1>High efficiency, air or water cooled metal-ceramic triode tube
2>High Voltage Transformer adjustable in 5 levels to adapt the HF generator for various sized operations
3>Centrifugal fan for optimum cooling of triode tube
4>Motorized controlled variable Anode and Grid Capacitors
5> high efficiency oscillating circuit of the HF generator controlled by ampere meters and variable capacitors to ensure the right value of the generator
6>Standard HF output from both sides
7>Double timer for working cycle
8>Protections against overheating and overloads
Specifications |
Power |
Input power |
Oscillation power |
Working frequency |
Applicable scope |
GJJ-5.0-DX |
~380V 50-60Hz |
6KW |
5KW |
6.78~13.56MHz |
Agglutination, Dry, Brake forming
for wood ware, wooden crafts
|
GJJ-10.0-DX |
~380V 50-60Hz |
15KW |
10KW |
6.78~13.56MHz |
|
GJJ-20.0-DX |
~380V 50-60Hz |
30KW |
20KW |
6.78~13.56MHz |
|
GJJ-30.0-DX |
~380V 50-60Hz |
40KW |
30KW |
6.78~13.56MHz |
|
GJJ-50.0-DX |
~380V 50-60Hz |
60KW |
50KW |
6.78~13.56MHz |
|
GJJ-75.0-DX |
~380V 50-60Hz |
90KW |
75KW |
6.78~13.56MHz |
|
GJJ-100.0-DX |
~380V 50-60Hz |
120KW |
100KW |
6.78~13.56MHz |
