Help Center3 Year Warranty 100-277VAC 30W/50W/80W/90W/100W COB LED Street Light
Related Products
Features:
1. Luminous efficiency :110-120LM / W
2. Long life: LED lamp life of up to 5-7 years;
3. Low heat, no hot-radioactive, no mercury, sodium and other elements harmful to human health;
4. Beneficial to the environment: LED light for all-solid-body impact resistance is not easy broken, waste recycling, pollution-free can be called the "Green Color illumination light source;
5. Adapt to the environment strong: in the -20 -60 °C, humidity ≤ 65% of the environment.
6. Energy saving up to 70-90%;
7. Realistic lighting effect without light distortion.
Power factor testing
Basic information
| Iten No. | PL-LD-GL30W |
| Net Weight | 4.5KG |
| Dimension | 480*250*90mm(mm) |
| Light Source Power | 30W |
| Total power | 40W |
| Light Efficiency | ≥80-100LM/W |
| Color temperature | warm white: 3000K-4000K White:5000-6500K |
| Input Voltage | DC12/DC24V/AC90V~265V |
| Input Frequency | 50~60HZ |
| Output Current | 3200~3300mA |
| Driving Power Factor | >0.90 |
| Driving Power Transformation Efficiency | >85% |
| View Angle | Horizontal: 180degree, Vertical: 60degree |
| Luminous Decay | <3% after 1,000hrs |
| Life Span | >50,000hs |
| Light Spot Shape | Zonal Facula |
| Working Temperature Scope | -20°C~60°C |
| Storage Temperature Scope | -20°C~60°C |
| Light Source Lumious Flux | 3000LM |
| Radiation Range | 6M:30Mx12M |
| 8M: 42Mx14M | |
| Illuminance | 6M: >80LUX |
| 8M: >51LUX |
100w LUX test
| Distance | Lux |
| 1m | 1979Lux |
| 2m | 599Lux |
| 3m | 280Lux |
| 4m | 180Lux |
| 5m | 110Lux |
| 6m | 80Lux |
| 7m | 62Lux |
| 8m | 51Lux |
| 9m | 46Lux |
Applications:
1 applied to urban sub-trunk roads and residential roads and sidewalk lighting
2 for the landscape lamp, courtyard lighting
3 applies to solar and wind-powered lighting.
4 applies to mines, ships, machine tools and other lighting.
5 can directly replace the incandescent lamp, energy-saving lamps, electrodeless lamps, mercury lamp, sodium lamp without the need to replace the original holde
